RS11 Organic Solid-core Resistor 0.5W 100 Ohm 5% Carbon Composition Resistor for Smart Meters
Price:
Negotiable
MOQ:
1000PCS
Delivery Time:
2-3 Weeks
Brand:
CNAMPFORT
Product Description
RS11 Organic Solid-core Resistor 0.5W 100R 5% 10% Carbon Composition Resistor
The high pulse withstanding capability of the RS11 series of carbon composition resistors from CNAMPFORT Resistor offers designers a compact solution for applications involving high voltages and high-energy pulses.
Product Overview
While many resistor manufacturers claim to offer carbon composition replacements, wirewound or thick film alternatives do not fully match the pulse performance and low inductance of carbon composition. CNAMPFORT offers carbon composition resistors made from a solid rod of conductive composite material, with chemical composition altered to produce different resistance values.
Construction
Organic solid-core resistors are made by mixing conductive substances such as carbon black and graphite with fillers and organic binders to form a powder, which is then hot-pressed into a plastic shell after special preparation. The leads are directly pressed into the resistor body.
Key Advantages
- High mechanical strength, good reliability, and strong overload capacity
- Wide resistance range
- Facilitates automated production and is affordable
- High pulse handling capability due to entire rod conduction and higher thermal mass
Technical Specifications
| Body length | 10mm |
| Body diameter | 3.5mm |
| Rated voltage | 223.6V |
| Max overload voltage | 559V |
| Resistance | 100 Ohm |
| Rated power | 0.5W |
Product Features
- Low inductance, solid rod carbon composition
- High pulse withstanding and high energy capability
- Resistance tolerance J(±5%), K(±10%) and M(±20%)
- Products with Pb-free terminations and RoHS compliant
- Power rating 1/4W and 2W, resistance range 1.8Ω ~ 22KΩ
Applications
The RS11 organic solid-core resistor is an insulating type resistor constructed by tightly embedding leads within the ends of a rod-shaped organic body. Its internal core resistor material is protected by a moisture-resistant and insulating thick outer coating material, providing extremely high reliability, good pulse resistance, and stable quality.
- Strobe lighting, high power lighting
- Medical defibrillators, welding, automotive systems
- Protection circuits (discharge circuits, surge protection)
- Inrush current limiting, high voltage power supplies
- Information appliances, color televisions, horizontal output transformers
- Electronic computers and high-reliability circuits
