Product Description Of The Auto Blade Fuse Holder WXFH-DFS101
WXFH-DFS101 is MAXI waterproof Fuse holder,Max 120A Voltage 86vdc,which is widely applied in Engineering vehicle circuit protection.
Application Of The Auto Blade Fuse Holder WXFH-DFS101
It can be used for power circuit protection of aviation, ships, deep water equipment, new energy, automobiles, toy cars, electric vehicles, medical instruments, wiring harnesses, lawn mowers, LED lights, power tools, garden tools, low current equipment, navigators, etc. Passed, South German TUV IATF16949 certification.
Features Of The Auto Blade Fuse Holder WXFH-DFS101
* IP68 Waterproof
* Dust-proof
* Withstand temperature -40~+220C
* Material: PVC+H62 Copper
* Current ratings: 30A~120A
* Customization on cable UL1015 6~12AWG
Dimension in mm Of The Auto Blade Fuse Holder WXFH-DFS101
| Number | Material | Explanation |
| 1 | PVC | UL 94 V0 environmental protection, modified PVC, environmental protection, heat dissipation |
| 2 | Contact | H62 brass nickel plating |
| 3 | Cable | UL1015 type 6 -12AWG 600v , The red line is 280mm long with both ends exposed. |
Electrical Characteristic Of The Auto Blade Fuse Holder WXFH-DFS101
| For Fuse | Max Ampere | Rated Voltage | Waterproof | Insulation Resistance | Di-electronic Strength | Installation |
| Maxi Blade Fuse | 120A | 86V | IP68 | >100MOHM | >1000Vac/60'' |
Terminal interface, welding |
Function of the fuse holder
* Load Function
At the beginning we mentioned that the fuse holder is an accessory for placing the fuse. Arrange the various fuses on the fuse holder in a certain order so as not to disrupt the function of each fuse. At the same time, because it is a special place for placing fuses, it provides considerable convenience for the discovery and maintenance of subsequent problems. Therefore, we can say that the fuse holder has the function of carrying, which is convenient for subsequent use and maintenance.
* Protection Function
The primary function of the fuse holder is the protection function, which plays a certain role when it is necessary to protect electrical appliances and fuses. Generally speaking, the rated current of the fuse is higher than the current used by our electrical appliances, and it also has a certain overload capacity. However, if our current margin is too large, it will cause the protection of the fuse. At this time, the fuse holder plays a protective role and acts as a fuse.
