Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Gigabit Industrial Unmanaged Fiber Media Converter
Introduction to Industrial Media Converter
- IM-MC110GE series is the 10/100/1000 Mbps industrial unmanaged fiber switch
- operating temperature -40 ℃ to + 75 ℃
- support wide voltage dual power input
- meet IP40 protection degree and EMC industrial grade requirements
- DIN rail installation
- pass through dangerous environmental certification and comply with FCC and CE standards
Key Features of Rugged Ethernet Optic Converter
- 1 x 10/100/1000Mbps Auto-sensing RJ45 ports
- 1 x 1000Mbps ST duplex fiber port
- 6 KV Ethernet surge protection, adapt to a harsh outdoor environment
- Support Auto MDI/MDIX
- Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
- IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
- A store-and-forward switching mechanism
Specification of Fiber Optic Ethernet Converter
| Product Name | 10/100/1000Mbps Industrial Fiber Media Converter (1TP+1F) |
| Model No. | IM-MC110GE-ST |
| Port |
1 x 1000Mpbs port SM:1310nm/1550nm, 20Km MM:1310nm, 2Km; 850m, 500m 1x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing) |
| Switching features |
Transmission mode: storage and forward System bandwidth: 4Gbps (non-traffic jam) Packet Forwarding Rate: 2.976Mpps MAC: 4K Queue Buffer: 1.75M |
| Network media |
10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m) 100BASE-TX: CAT5 or above shielded twisted pair(≤100m) SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km |
| LEDs | Power, network, fiber |
| Power supply |
Input voltage: DC 12-52V No-load power:5W Reverse connection: support |
| Environment |
Working temperature:-40°～75°C Storage temperature:-40°～ 85°C Working humidity:10%～90%,non-condensing Storage humidity:10%～95%,non-condensing |
| Industry Standards |
EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8 Traffic Control:NEMA-TS2 Vibration:IEC 60068-2-6 Freefall:IEC 60068-2-32 Shock:IEC 60068-2-27 Rail Traffic:EN 50121-4 |
| Safety |
CE Mark ,commercial CE/LVD EN60950 |
| Mechanical information |
Shell:Corrugated metal shell Safety class:IP40 Dimension: 113.8 x 93 x 34.9mm Mounting method:Din-rail mounting Weight: 0.35kg |
| Warranty | Replacement within 1 year; 3 years repairing |
Size of Unmanaged media converter
FAQ
1 Q: What is your lead time?
A:It usually takes 2~4 working days to produce and then will send goods.
2 Q: How will you send my goods?
A: We will send the goods by DHL, TNT, UPS or FEDEX, please check the delivery details by the tracking number.
3 Q: Please tell me something about your MOQ
A: Our MOQ is 1 Pcs/Pair based on USD or EUR terms.
4 Q: Something about pricing.
A: Good quality components for our products. Low prices for big and repeat orders.
