4 Port Gigabit PoE Switch 60W Budget SFP Fiber Unmanaged With VLAN 250-Meter Extension

Name: 4 Port Gigabit PoE Switch 60W Budget SFP Fiber Unmanaged With VLAN 250-Meter Extension
Brand: Shenzhen Olycom Technology Co., Ltd.

Price Negotiable

Price: negotiable

MOQ: 1pc

Delivery Time: 4~7 working days

Brand: Olycom

Product Description

4 port Commercial Gigabit PoE Fiber Switch with 2 optical uplink

Specification of PoE Fiber Switch

I/O Interface
Power	Input: AC 100-240V, 50/60Hz
Ethernet	410/100/1000M PoE Port 2 Gigabit SFP Uplink Port
Performance
Switching Capacity	12Gbps
Throughput	8.928Mpps
Packet Buffer	1Mbit
MAC Address	2K
Jumbo Frame	9216bytes
Transfer Mode	Store and forward
MTBF	100000 hour
Standard
Network protocol	IEEE802.3 (10Base-T) IEEE802.3u (100Base-TX) IEEE802.3ab(1000Base-TX) IEEE802.3z(1000Base-FX) IEEE802.3x (Flow control)
PoE Protocol	IEEE802.3af (15.4W) IEEE802.3at (30W)
Network Medium	10Base-T : Cat3,4,5 or above UTP(≤100m) 100Base-TX : Cat5 or above UTP(≤100m) 1000Base-TX : Cat5 or above UTP(≤100m)
Optical Media	Multimode fiber : 50/125, 62.5/125, 100/140μm Single mode fiber: 8/125, 8.7/125, 9/125, 10/125μm

Protection
Security Certificate	CE,FCC,RoHS
Environment
Working Environment	Working Temperature:-10~50°C Storage Temperature:-40~70°C Working Humidity :10%~90%,non-condensing Storage Temperature:5%~95%,non-condensing
Indication
PWR(power supply)	Lighting:Powered Un-Light:No Power
Mode(DIP)	Lighting:VLAN Un-Light:Default Flashing:Extend
1-6 Gree(Link&Data)	Lighting:Connecting Flashing:Data Transmit Un-Light:Disconnect
DIP Switch	VLAN:Port isolation mode. In this mode, the PoE ports (1-4) of the switch cannot communicate with each other, and can only communicate with the UP-link port. Default : Normal mode, all port can communicate with each other, the transmission distance is within 100 meters Extend:Link extension mode, 3-4 ports PoE power supply and data transmission distance can be extended to 250 meters, the transmission rate becomes 10M
Mechanical
Structure Size	Product Dimension : 20011844.5mm Package Dimension : 24519060mm N.W:0.63kg G.W:0.93kg
Packing Info	Carton MEAS:520320400mm Packing Qty:20units Packing Weight:19.6KG
Power Voltage	Input Voltage :AC 100-240 V Power supply:52V1.25A
power	Product power: maximum 5W POE power: maximum 60W
Package List	Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification 1 pc

Key Features of Gigabit Ethernet Switch

4*10/100/1000M POE Ports + 2*1000M SFP Port
Comply with IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z standards
Ethernet port 10/100/1000M rate auto adaptive
Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard
Support Port Auto-flip (Auto MDI/MDIX)
Panel indicators to monitor working status and help fault analysis
One-key smart switch, supports VLAN, Default, Extend

How do Olycom produce an item?

Welding: Weld the necessary components
Cleaning: To avoid any possible dysfunction due to dust or scraps on the PCB boards.
Assembling: Builds up components of a product, like panels, screws, PCB boards.
Testing: To make sure the product is basically working fine after assembling
Aging: To check if the product can work smoothly for long time without any minors such as LED indicators, voltage. This will usually last for 24 to 48 hours.
Testing: To test if the product can process data or video signals correctly. Any data loss? Transmission rate correct? Any data packet failure? Such questions would be verified in this procedure.
QC testing: This is the third and also last check of product quality. If it goes good, our packing staff will pack it up according to customer requirements and attach to the packing box a product label.

When all above is done, the product will go to market.

Warranty Terms

1 year for commercial products and 3 years for industrial products. Technical support will be offered free.
