High Temperature Melt Pressure Transmitter 10VDC Melt Pressure Sensor

High temperature melt pressure transmitter for Plastic fiber, spinning, polyester, rubber solid liquid

Introduction

PT124 Series Melt Pressure Transducer can achieve the pressure and temperature measuring. This series adopt special material and alloy elastic membrane to low down temperature draft and improve accuracy. The zero & full span can be calibrated, with amplify signal be connected with PLC, and internal 80% calibration. It has the wide application in high-temp liquid pressure measurement and control such as Chemical & Fiber equipment, polyester equipment, etc.

PARAMETERS
Range: 0….10Mpa to 0….150MPa (0…1500psi to 0…20000psi)
Output: 3.33mV/V; 2mV/V ; 4~20mA ; 0~10V
Accuracy: ±0.5%FS
Excitation: 10VDC (6--12VDC)
Repeatability: ±0.2%
Diaphragm material: 15-5PH
Bridge resistance: 350 ohms±10%
Overload pressure: 1.5×FSO
Internal calibration: 80%FSO±1%
Insulation Resistance: 1000Megohms @50Vdc
Max. Diaphragm Temp: 350℃
Electric connector: 5PIN, 6PIN, 8PIN
Process connector: M14×1.5, [M18×1.5,1/2″-20UNF](Customer design)
Rigid stem length:6"(152mm) , 9"(230mm)
Flexible stem length:18"(460mm)
