XJBN-00514 Travel Motor Seal Kit Walking Motor R360LC-7 R370LC-7 Hyundai Spare Parts
XJBN-00514 Travel Motor Seal Kit For Hyundai Walking Motor R360LC-7,R370LC-7 Hydraulic Seal Kit
Model:Hyundai XJBN-00514 Travel motor seal kit
Part number:XJBN-00514
Motor number:31NA-40010
For:Hyundai R360LC-7,R370LC-7
Material:PU+NBR+PTFE
CertifiCATEEion:IOS 9001
Packaging Details: bag or box +carton
Delivery Time:2-5days upon payments confirmed
Brand:Bulldog
Payment Terms:T/T, Western Union, MoneyGram, Paypal, Alipay
Delivery method:DHL,FedEx,UPS,etc.
Supply Ability:50
MOQ:1set
Parts list
| NO. | Part number | name | quantity |
| * | 31NA-40010 | Travel Motor[T] | 1 |
| *-1 | XJBN-00519 | . Travel Motor Unit | 1 |
| 022 | XJBN-00513 | .. Spool-C/Balance | 1 |
| 101 | XJBN-00512 | .. Shaft-Drive | 1 |
| 102 | XJBN-00511 | .. Bearing-Roller | 1 |
| 103 | XJBN-00510 | .. Bearing-Needle | 1 |
| 106 | XJBN-00509 | .. Spacer-Bearing | 1 |
| 107 | XJBN-00600 | .. Ring-Snap | 1 |
| NS111 | XJBN-00507 | .. Block-Cylinder | 1 |
| 113 | XJBN-00506 | .. Bushing-Spherical | 1 |
| 114 | XJBN-00022 | .. Spring-Cylinder | 9 |
| 116 | XJBN-00368 | .. Spacer | 1 |
| NS121 | XJBN-00504 | .. Piston | 9 |
| NS122 | XJBN-00503 | .. Shoe | 9 |
| 123 | XJBN-00020 | .. Plate-Set | 1 |
| NS131 | XJBN-00638 | .. Plate-Valve | 1 |
| 161 | XJBN-00403 | .. O-Ring | 2 |
| 162 | XJBN-00397 | .. Ring-Back Up | 2 |
| 201 | XJBN-00502 | .. Plate-Swash | 1 |
| 202 | XJBN-00501 | .. Supprot | 1 |
| NS272 | XJBN-00500 | .. Casing | 1 |
| NS303 | XJBN-00499 | .. Casing-Valve | 1 |
| 304 | XJBN-00498 | .. Cover-Seal | 1 |
| 350 | XJBN-00497 | .. Valve-Relief | 2 |
| 361 | XJBN-00496 | .. Washer | 2 |
| 362 | XJBN-00495 | .. Spring-C/Balance | 2 |
| 364 | XJBN-00494 | .. Cover-C/Balance | 2 |
| K365 | XJBN-00493 | .. O-Ring | 2 |
| 366 | XJBN-00492 | .. Bolt-Socket | 8 |
| 401 | XJBN-00491 | .. Bolt-Socket | 8 |
| 402 | XJBN-00490 | .. Bolt-Socket | 4 |
| 435 | XJBN-00489 | .. Ring-Snap | 1 |
| S451 | XJBN-00053 | .. Pin-2 | 1 |
| S452 | XJBN-00488 | .. Pin-1 | 2 |
| 461 | XJBN-00032 | .. Plug | 10 |
| 464 | XJBN-00409 | .. Plug | 4 |
| K471 | XJBN-00286 | .. O-Ring | 1 |
| K472 | XJBN-00486 | .. O-Ring | 1 |
| K485 | XJBN-00097 | .. O-Ring | 4 |
| K491 | XJBN-00485 | .. Seal-Oil | 1 |
| 501 | XJBN-00484 | .. Piston-Tilting | 1 |
| 502 | XJBN-00483 | .. Piston-Tilting | 1 |
| 503 | XJBN-00482 | .. Stopper | 1 |
| 504 | XJBN-00481 | .. Stopper-S | 1 |
| 505 | XJBN-00480 | .. Rod-Tilting | 1 |
| 506 | XJBN-00479 | .. Screw | 2 |
| 507 | XJBN-00478 | .. Nut | 2 |
| K508 | XJBN-00477 | .. O-Ring | 1 |
| K509 | XJBN-00283 | .. O-Ring | 2 |
| K510 | XJBN-00398 | .. Ring-Back Up | 1 |
| K511 | XJBN-00475 | .. O-Ring | 1 |
| K512 | XJBN-00474 | .. Ring-Back Up | 1 |
| 531 | XJBN-00473 | .. Spool-Tilting | 1 |
| 533 | XJBN-00472 | .. Spring-Tilting | 1 |
| 541 | XJBN-00471 | .. Seat | 2 |
| 542 | XJBN-00470 | .. Stopper | 2 |
| 543 | XJBN-00359 | .. Ball-Steel | 2 |
| 545 | XJBN-00469 | .. Orifice | 1 |
| 546 | XJBN-00468 | .. Orifice | 2 |
| K547 | XJBN-00231 | .. O-Ring | 3 |
| 567 | XJBN-00356 | .. Plug | 7 |
| K568 | XJBN-00362 | .. O-Ring | 7 |
| 571 | XJBN-00639 | .. Plug | 1 |
| K572 | XJBN-00233 | .. O-Ring | 1 |
| 702 | XJBN-00640 | .. Piston-Brake | 1 |
| 705 | XJBN-00466 | .. Spring-Brake | 10 |
| K707 | XJBN-00465 | .. Ring 252-Piston | 1 |
| K708 | XJBN-00464 | .. Ring 278-Piston | 1 |
| S709 | XJBN-00463 | .. Pin-Center | 4 |
| 710 | XJBN-00462 | .. Guide-Spring | 1 |
| 711 | XJBN-00641 | .. Spool | 1 |
| 712 | XJBN-00460 | .. Bushing | 1 |
| 713 | XJBN-00459 | .. Spring | 1 |
| 714 | XJBN-00458 | .. Plug | 1 |
| 741 | XJBN-00457 | .. Plate-Separator | 1 |
| 742 | XJBN-00456 | .. Plate-Friction | 2 |
| 801 | XJBN-00156 | .. Name Plate | 1 |
| 802 | XJBN-00341 | .. Pin | 2 |
| *-2 | @ | . T/Reduction Gear[T] | 1 |
| K | XJBN-00514 | Seal Kit[T] | 1 |
| 011 | XJBN-00515 | Valve Casing Sub A...[T] | 1 |
| 012 | XJBN-00516 | Casing Sub Assy[T] | 1 |
| 013 | XJBN-00517 | Cylinder Sub Assy[T] | 1 |
| 014 | XJBN-00518 | Piston Sub Assy[T] | 1 |
Parts exploded view
More service models
| New Komatsu Style 707-99-68780 Hydraulic Cylinder Seal Kit. | ||||||
| This is a New Seal Kit that fits the following Models and Cylinder part numbers. | ||||||
| Model Num. | AppliCATEEion | Cylinder | Rod Size (in) | Bore (in) | Serial Num. | Part # |
| PC400-7, PC400LC-7 | ARM | 707-01-0F690 | 120 mm | 185 mm | 50001-50146 | KOM-707-99-68780 |
| PC400-7, PC400LC-7 | ARM | 707-01-0F691 | 120 mm | 185 mm | 50147- | KOM-707-99-68780 |
| PC400-7, PC400LC-7 | ARM | 707-01-0F741 | 120 mm | 185 mm | 50001- | KOM-707-99-68780 |
| PC400-7, PC400LC-7 | ARM | 707-01-0F810 | 120 mm | 185 mm | 50001- | KOM-707-99-68780 |
| PC400-7, PC400LC-7 | ARM | 707-01-0F840 | 120 mm | 185 mm | 50001- | KOM-707-99-68780 |
| PC400-7, PC400LC-7 | ARM | 707-01-0G370 | 120 mm | 185 mm | 50001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0F691 | 120 mm | 185 mm | 60001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0F691 | 120 mm | 185 mm | A87001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0F741 | 120 mm | 185 mm | 60001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0F741 | 120 mm | 185 mm | A87001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0F810 | 120 mm | 185 mm | 60001- | KOM-707-99-68780 |
| PC400-7E0, PC400LC-7E0 | ARM | 707-01-0G370 | 120 mm | 185 mm | 60001- | KOM-707-99-68780 |
| PC400LC-7L | ARM | 707-01-0F690 | 120 mm | 185 mm | A86001- | KOM-707-99-68780 |
| PC450-7K | ARM | 707-01-0F691 | 120 mm | 185 mm | K40001- | KOM-707-99-68780 |
| PC450-7K | ARM (2.4M Arm) | 707-01-0F741 | 120 mm | 185 mm | K40001- | KOM-707-99-68780 |
Company warehouse
FAQ
1. Q: Are you a manufacturer or trader?
A: We are both in manufacturer and trader, have more than 10 years
of industry experience.
2. Q: Can i make a small order first?
A: Yes, of course.
3. Q: If we let the product make a change of the size, can you offer the
seal kit for this size?
A: Yes, just send the machine model, part number and the change
of size to us, we can make it.
4. Q: Have you support the OEM or not?
A: Sure, we support the OEM,BULLDOG or as required.
5. Q: How can i pay the goods?
A: For the payment, we support the PayPal, Western Union, Money Gram, T/T in advance, L/C at sight, etc
6. Q: How to ship the products?
A: For the shipment, we support the DHL Fedex EMS UPS or by Air/ Sea., if you have the agent in china, we can contact your agent according to your request.
7. Q: What’s the delivery time?
A: The goods can be shipped at 2-5 working days after receiving payment.
