PC138US-8 Komatsu Excavator Seal Hydraulic Cylinder Repair Kits 707-99-38440
707-99-38440 7079938440 Arm Cylinder Seal Kit PC138US-8 Komatsu Excavator CYL Service
| Product Name | 707-99-38440 Komatsu Arm Cylinder Seal Kit |
| Model Number | KOMATSU PC138US-8 |
| Place of Origin | China(Mainland) |
| Brand name | BULLDOG |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.) |
| Part Number | 707-99-38440, 7079938440 |
| Payment Terms | Western Union, L/C, T/T, Money Gram, D/A, D/P |
| CertifiCATEEion | ISO9001 |
| Condition | 100% New |
| Warranty | Unavailable |
| Customized | OEM & ODM are welcomed |
| AppliCATEEion | Komatsu excavator |
| Preservation Notice | Closed, dry and avoid the sun |
| Quality | Original quality, high performance |
| Feature | High chemical resistance, oil resistance |
| CATEEalog | Cylinder seal kits |
| Size | Standard size |
Parts On Group:
Related Parts:
| Pos. | Part No | Qty | Parts name |
| G1. | 707-03-X0330 | [1] | CYLINDER GROUP,ARM |
| 707-03-00330 | [1] | CYLINDER ASS'Y,ARM | |
| 1. | 707-14-11080 | [1] | CYLINDER,ARM |
| 2. | 21Y-70-31470 | [2] | BUSHING |
| 3. | 07145-00080 | [2] | SEAL,DUST (KIT) |
| 4. | 707-58-75890 | [1] | ROD,PISTON |
| 5. | 22B-70-23620 | [1] | BUSHING |
| 6. | 07145-00070 | [2] | SEAL,DUST (KIT) |
| 7. | 07020-00000 | [1] | FITTING,GREASE |
| 8. | 707-27-11650 | [1] | HEAD,CYLINDER |
| 9. | 707-52-90500 | [1] | BUSHING |
| 10. | 707-51-75030 | [1] | PACKING,ROD (KIT) |
| 11. | 707-51-75650 | [1] | RING,BUFFER (KIT) |
| 12. | 07000-15100 | [1] | O-RING (KIT) |
| 13. | 707-35-91130 | [1] | RING,BACK-UP (KIT) |
| 14. | 707-56-75740 | [1] | SEAL,DUST (KIT) |
| 15. | 07179-13089 | [1] | RING,SNAP |
| 16. | 01010-81670 | [12] | BOLT |
| 17. | 01643-51645 | [12] | WASHER |
| 18. | 707-36-11020 | [1] | PISTON |
| 19. | 707-44-11150 | [1] | RING,PISTON (KIT) |
| 20. | 707-39-11150 | [2] | RING,WEAR (KIT) |
| 21. | 707-44-11911 | [2] | RING |
| 22. | 707-71-80230 | [1] | PLUNGER |
| 23. | 04260-00635 | [11] | BALL |
| 24. | 707-71-91270 | [1] | CAP |
| 25. | 01310-01216 | [1] | SCREW |
| 26. | 07000-15070 | [1] | O-RING (KIT) |
| 27. | 707-35-90360 | [2] | RING,BACK-UP (KIT) |
| 28. | 707-83-13010 | [1] | VALVE |
| 29. | 07750-01628 | [1] | SPRING |
| 30. | 707-87-14070 | [1] | PLUG |
| 31. | 07002-12034 | [1] | O-RING (KIT) |
| 32. | 707-75-75110 | [1] | RING,SNAP |
| 33 | 707-86-55670 | [1] | TUBE |
| 34 | 21Y-62-31831 | [1] | TUBE |
| 35 | 07000-13025 | [2] | O-RING (KIT) |
| 36 | 01010-80850 | [4] | BOLT |
| 37 | 01643-30823 | [4] | WASHER |
| 38 | 707-88-95950 | [1] | BAND |
| 39 | 21Y-62-31861 | [1] | BRACKET |
| 40 | 07372-21035 | [2] | BOLT |
| 41 | 01643-51032 | [2] | WASHER |
| 42 | 07283-32236 | [2] | CLIP |
| 43 | 01597-01009 | [4] | NUT |
| 44 | 01643-31032 | [4] | WASHER |
| 45 | 702-21-08830 | [1] | PILOT VALVE |
| 47 | 01010-80860 | [2] | BOLT |
| 50 | 01010-80830 | [4] | BOLT |
| K. | 707-99-38440 | [1] | SERVICE KIT, ARM CYLINDER |
Parts exploded view
More service models
| D65E-12 | |||||||
| LIFT | 14X-63-01063 | 65 mm | 95 mm | KOM-707-98-28600 | |||
| 14X-63-01063 | 65 mm | KOM-707-52-10660 | |||||
| LIFT (TRIMMING) | 14X-63-07011 | 65 mm | 95 mm | KOM-707-98-28600 | |||
| 14X-63-07011 | 65 mm | KOM-707-52-10660 | |||||
| 14X-63-07012 | 65 mm | 95 mm | KOM-707-98-28600 | ||||
| 14X-63-07012 | 65 mm | KOM-707-52-10660 | |||||
| RIPPER | 14X-63-01052 | 70 mm | 140 mm | KOM-707-98-52130 | |||
| 14X-63-01052 | 70 mm | KOM-707-52-10700 | |||||
| TILT | 14Y-63-01032 | 70 mm | 140 mm | KOM-707-98-52140 | |||
| 14Y-63-01033 | 70 mm | 140 mm | KOM-707-98-52140 | ||||
| 707-01-0C300 | 70 mm | 140 mm | KOM-707-98-52210 | ||||
| 707-01-0C301 | 70 mm | 140 mm | KOM-707-99-52160 | ||||
| TRIMMING LH | 14X-63-07030 | 55 mm | 120 mm | KOM-707-98-40020 | |||
| 14X-63-07030 | 55 mm | KOM-07177-05530 | |||||
| TRIMMING RH | 14X-63-07040 | 55 mm | 120 mm | KOM-707-98-40020 | |||
| 14X-63-07040 | 55 mm | KOM-07177-05530 | |||||
