Gdz80-2.2 2.2kw Vfd Cnc Spindle Motor Er16 Er11 Er20 Water Cooled 80mm
Water cooled spindle motor electrical Specification
| TYPE | speed(rpm) | motor | Shaft end link | Lubrication | Cooling | Weight(kg) | ||||
| power(kw) | voltage(V) | current(A) | frequency(HZ) | diameter(mm) | ||||||
| GDZ48-300 | 60000 | 0.3 | 75 | 4.5 | 1000 | Φ48 | ER8 | grease | water cooling | |
| GDZ62-1.2 | 24000 | 1.2 | 178 | 5 | 400 | Φ62 | ER11 | grease | water cooling | |
| GDZ62-1.2 | 36000 | 1.2 | 220 | 4.5 | 600 | Φ62 | ER11 | grease | water cooling | 4.4 |
| GDZ62-1.2 | 60000 | 1.2 | 220 | 4.5 | 1000 | Φ62 | ER11 | grease | water cooling | 4.4 |
| GDZ65-800 | 24000 | 0.8 | 110 150 220 | 3.9 6.0 5.0 | 400 | Φ65 | ER11 | grease | water cooling | 2.6 |
| GDZ65-1.5 | 24000 | 1.5 | 220 | 5.5 | 400 | Φ65 | ER11 | grease | water cooling | 3.6 |
| GDZ80-1.5,ER16 | 24000 | 1.5 | 220 | 5 | 400 | Φ80 | ER16 | grease | water cooling | 5 |
| GDZ80-2.2B,ER20 | 24000 | 2.2 | 220 380 | 8 5 | 400 | Φ80 | ER20 | grease | water cooling | 5 |
| GDZ85-1.5 | 24000 | 1.5 | 380 | 5 | 400 | Φ85 | ER20 | grease | water cooling | 13 |
| GDZ85-2.2 | 24000 | 2.2 | 380 | 7.5 | 400 | Φ85 | ER20 | grease | water cooling | 13 |
| GDZ100-3 | 24000 | 3 | 220 380 | 10 5.8 | 400 | Φ100 | ER20 | grease | water cooling | 9 |
| GDZ100-4 | 24000 | 4 | 220 380 | 13.8 8 | 400 | Φ100 | ER20 | grease | water cooling | 11.6 |
| GDZ125-4.5 | 24000 | 4.5 | 380 | 8 | 400 | Φ125 | ER25 | grease | water cooling | 22 |
| GDZ125-5.5 | 24000 | 5.5 | 380 | 9 | 400 | Φ125 | ER25 | grease | water cooling | 22 |
Different views of Spindle
We have standard package for our products
1. Sample order lead time is in 5 days. Mass quantity order lead time is 7-10 days.
2. We can accept payment via paypal, Western Union, Money Gram, T/T, L/C
3. We can provide you professional technical support. And our products quality gurantee is 18 months.
4. We accept products customize.
Our main products include from size NEMA 8 to NEMA 42 series hybrid stepper motor, and variable sizes linear stepper motor, stepper motor with gear box, stepper motor with brake and spindle motor . And by now we have new products about closed loop systems for nema 23, nema 24 and nema 34 sizes. In addition, we can produce suitable drivers for all the motors. And we always research and develop new products.
Certification
1.Q:Can I get some samples first?
A:Sure, we are honored to offer you samples for your check.
2.Q:Do you have the products in stock?
A:Our products are manufactured according to your order except the normal products.
3.Q:What's the delivery time?
A:It usually takes about 7 working days,but the exact delivery time might be different for different order or at different time.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the beginning to the end of the production. Every product will be fully assembled and carefully tested before packed.
5.Q:What's your warranty terms?
A: We offer different warranty terms for different products. Please contact with us for details.
