High Torque Brushless Dc Motor 24V 125W 3000rpm 57mm Flange Square Shape
Price:
Negotiable
MOQ:
1 pcs
Delivery Time:
25days
Brand:
JSS
Product Description
Industrial 57mm Brushless Dc Motor Flange 24V 3000rpm Square Shape 125W
Our products are widely applied in engraving machine, cutting plotter, textile machine, 3D printer, medical instruments, stage light equipment, robot, CNC, music fountain, and other industrial automatic equipment..
Our products are exported to all over the world, including Europe, South America, North America, Africa, Southeast Asia, etc.
We can solve the actual using problems for customers. Our products are highly commended by customers because of its easy operation, long using life, stable performance.
General specification:
| Item | Specification |
| Widing type | Star/Delta |
| Hall effect angle | 120 degree electrice angle |
| Shaft runout | 0.025mm |
| Radial play | 0.02mm/50g |
| End play | 0.08mm/50g |
| Max radial force | 75N/20mm from the flange |
| Max axial force | 15N |
| Insulation class | Class B |
| IP class | IP 40 |
| Dielectric strength | 500VDC for one minute |
| Insulation Resistance | 100MΩmin 500VDC |
Electrical Specification:
| Model | Rated Voltage | Rated Current | Rated Power | Rated Torque | Peak Torque | Rated Speed | Length | Mass |
| (VDC) | (A) | (W) | (N.m) | (N.m) | (RPM) | (mm) | (kg) | |
| 57BL60-230 | 24 | 3.4 | 62 | 0.2 | 0.6 | 3000 | 60 | 0.65 |
| 57BL80-230 | 24 | 6.9 | 125 | 0.4 | 1.2 | 3000 | 81 | 0.85 |
| 57BL100-230 | 24 | 10.4 | 188 | 0.6 | 1.8 | 3000 | 102 | 1.1 |
Electrical Connection:
| Lead No. | Lead Color | Lead Gauge | Function | Description |
| 1 | Red | UL3266/28AWG | VCC+5VDC | SUPPLY VOLTAGE FOR HALL SENSORS |
| 2 | Black | GND | GROUND FOR HALL SENSORS | |
| 3 | Yellow | HALL A | SIGNAL OF HALL A | |
| 4 | Green | HALL B | SIGNAL OF HALL B | |
| 5 | Blue | UL3266/20AWG | HALL C | SIGNAL OF HALL C |
| 1 | Yellow | PHASE U | MOTOR PHASE U | |
| 2 | Green | PHASE V | MOTOR PHASE V | |
| 3 | Blue | PHASE W | MOTOR PHASE W |
Wiring diagram:
Dimensions:
(Unit=mm)
