Dc 48v 500w Er11 Brushless Spindle Motor Air Cooled 57mm
48V Air Cooled Spindle Motor Brushless Dc Motor 500W 12000rpm
Our main products include hybrid step motor, and step driver, step servo motor and driver, integrated step servo motor, linear stepper motor, geared stepper motor, stepper motor with brake, brushless dc motor. And we are always researching and developing new products.
Our products are widely applied in engraving machine, cutting plotter, textile machine, 3D printer, medical instruments, stage light equipment, robot, CNC, music fountain, and other industrial automatic equipment..
57mm Round Shape Brushless DC Motor:
| Item | Specification |
| Widing type | Star/Delta |
| Hall effect angle | 120 degree electrice angle |
| Shaft runout | 0.025mm |
| Radial play | 0.02mm/50g |
| End play | 0.08mm/50g |
| Max radial force | 75N/20mm from the flange |
| Max axial force | 15N |
| Insulation class | Class B |
| IP class | IP 40 |
| Dielectric strength | 500VDC for one minute |
| Insulation Resistance | 100MΩmin 500VDC |
Electrical Specification:
| Model | Rated Voltage(VDC) | Rated Current(A) | Rated Power(W) |
Rated Torque(N.m) |
Peak Torque(N.m) |
Rated Speed(rpm) |
Length(mm) |
| 57BLY90-4120 | 48 | 12 | 400 | 0.3 | 0.9 | 12000 | 120 |
| 57BLY110-4120 | 48 | 14 | 500 | 0.4 | 1.2 | 12000 | 140 |
Electrical Connection:
| Lead No. | Lead color | Lead gauge | Function | Description | ||||
| 1 | Yellow | UL3266/16AWG | PHASE U | MOTOR PHASE U | ||||
| 2 | Green | PHASE V | MOTOR PHASE V | |||||
| 3 | Blue | PHASE W | MOTOR PHASE W | |||||
Size: (mm)
Diagram:
Suitful holder :
