China 220V AC Servo Motor 750W 2000RPM 3.6NM 80mm 80DNMA2-0D75CKAM for sale

220V AC Servo Motor 750W 2000RPM 3.6NM 80mm 80DNMA2-0D75CKAM

Price Negotiable

Price: negotable

MOQ: 1PCS

Delivery Time: 25days

Brand: JSS-MOTOR

Product Description

750W 80mm AC Servo Motor rapidity servo drive system 2000RPM 3.6N.M

Main features:

Shortened positioning time

Quick instruction tracking

Response frequency up to 1KHZ bandwidth

Built-in RS485 conmmunication.

3-times overload

Grade 2 notch functions

Built-in dynamic brakes (optional)

Specifications:

	power	driver model	frame size	motor model	Speed(r/min)	Torque(N*m)
220VAC	200W	EPS-B1-0D20AA-A000	60	60DNMA2-0D20DKAM	3000	0.64
	400W	EPS-B1-0D40AA-A000	60	60DNMA2-0D40DKAM	3000	1.27
	750W	EPS-B1-0D75AA-A000	80	80DNMA2-0D75DKAM	3000	2.39
	1KW	EPS-B1-0001AA-A000	130	130DNMA2-0001DKAM	3000	3.18
	1KW	EPS-B1-0001AA-A000	130	130DNMA2-0001CKAM	2000	4.77
	1KW	EPS-B1-0001AA-A000	130	130DNMA2-0001AKAM	1000	9.55
	1.2KW	EPS-B1-01D5AA-A000	130	130DNMA2-01D2CKAM	2000	5.73
	1.2KW	EPS-B1-01D5AA-A000	110	110DNA-12CK1AMS	2000	5.73
	1.5KW	EPS-B1-01D5AA-A000	130	130DNMA2-01D5CKAM	2000	7.2
	1.8KW	EPS-B1-02D2AA-A000	130	130DNMA2-01D8DKAM	3000	5.73
	2.2KW	EPS-B1-02D2AA-A000	130	130DNMA2-0002CKAM	2000	9.55
	3KW	EPS-B1-0003AA-A000	130	130DNMA2-0003CKAM	2000	14.33
	3KW	EPS-B1-0003AA-A000	180	180DNA-30BK1AMS	1500	19.1
	4KW	EPS-B1-04D5AA-A000	180	180DNA-40BK1AMS	1500	25.5
	4.5KW	EPS-B1-04D5AA-A000	180	180DNA-45BK1AMS	1500	28.6
	5.5KW	EPS-B1-05D5AA-A000	180	180DNA-55BK1AMS	1500	35

Motor dimensions:

Driver Installation:

Our products are widely applied in engraving machine, cutting plotter, textile machine, 3D printer, medical instruments, stage light equipment, robot, CNC, music fountain, and other industrial automatic equipment..
