CNC Engraving Milling NEMA23 Stepper Motor 20kg.Cm Torque Hybrid Stepper Motor
CNC Engraving Milling NEMA23 Stepper Motor 20kg.Cmtorque Hybrid Stepper Motor
Our main products includes stepper motors, closed loop system, gear reducer stepper motor, linear stepper motor, brake stepper motor, stepper drivers, controller board, spindles, power supplys, and other accessories.
It can be applied in engraving machine, cutting plotter, textile machine, 3D printer, medical instruments, stage light equipment, robot, CNC, music fountain, and other industrial automatic equipment.a variety of small scale automation equipment and instruments, such as labeling machine, cutting machine, packing machine, drawing machine, It always performs well when it is used in equipment which requires for low-vibration, low-noise, high-precision and high-velocity.
Products Electrical specification:
| Model No | Step Angle(°) | Rated Voltage(V) | Rated Current (A) | Phase Resistance(Ω) | Phase Inductance (mH) | Holding Torque (Kg.cm) | Detent Torque(g.cm Max) | Rotor Inertia (g.cm²) | Motor Length (mm) | Leads No. | Motor Weight(Kg) |
| 57HS76-2004 | 1.8 | 8.6 | 2 | 4.3 | 16.2 | 24 | 680 | 480 | 76 | 4 | 1 |
| 57HS76-3004 | 1.8 | 2.7 | 3 | 0.9 | 3.5 | 20 | 680 | 480 | 76 | 4 | 1 |
| 57HS76-4004 | 1.8 | 2.4 | 4 | 0.6 | 2.2 | 20 | 680 | 480 | 76 | 4 | 1 |
| Above only for representative products,products of special request can be made according to the customer request. | |||||||||||
Motor Dimensions:
Wiring Diagram:
