100-250kg Pail Pesticide Chemical Filling Machine Automatic 30 Drums Per Hour
100-250kg Pail Drum Automatic Chemical Pesticide Filling Machine 30 Drums Per Hour With High Accuracy 0.2%
1 Introduction of CC-300C Automatic Chemical Pesticide Filling Machine
The CC300C Automatic weight chemical pesticide filling machine uses the newest weight filling system, enables the user to set the filling volume through the self-service interface, provides automatic filling, and has an adjustable filling speed. It can fill various liquids, both with and without foam, automatically.
2 Paramters of CC-300C Automatic Pesticide Filling Machine
| 1 | Applicable Drum Size | Max Φ580×930mm Round Drum |
| 2 | Filling Range | 100-250Kg |
| 3 | Filling Precision |
±0.2% |
| 4 | Capacity |
30 Drums/hour Capacity differs from product |
| 5 | Air Pressure/Consumption | 0.6-0.8MPa/100L/min |
| 6 | Power Source | ～380V 50Hz/2KW |
| 7 | External Dimension | 730×1300×3400mm(L×W×H) |
| 8 | Weight | About 350Kg |
3 Electrical Configuration of CC-300C Automatic Pesticide Filling Machine
| No. | Name | Brand |
| 1 | Weighing System | METTLER TOLEDO |
| 2 | PLC | Schneider |
| 3 | HMI | Schneider |
| 4 | Inverter | Schneider |
| 5 | Proximity Switch | Schneider |
| 6 | Button | Schneider |
| 7 | Alarm Light | Schneider |
| 8 | Circuit Breaker | Schneider |
4 Features of CC-300C Pesticide Filling Machine
Work process:Place the drum manually, Position the nozzle manually, Filling the pesticide, discharge the drum
Good Applicability:CC-300C weighing type filling machine is suitable to 100-250kg automatic pesticide filling.
Good Accuracy: Mettler Toledo loadcell ensures good accuracy
The machine uses France Schneider Control system to control the operating stability. Meanwhile, the control system is with low energy consumption.
5 FAQ
| Q: Are you prepared to solve problems quickly if your equipment has problems while running? | A: As soon as we receive the customer's problem, our engineer will analyze it based on pictures or videos. If there are some small problems, we will direct the customer how to solve the problem. if there are some parts breakdowns, the spare parts will be sent as soon as possible. |
| Q: What is the machine package? | A: We spray each machine with antirust oil, wrap it with PO film to protect it, and pack each one in a standard wooden case with no fumigation. |
