100-277VAC 120W 160w Led Industrial Flood Light Water Resistant Polarbear Series
Polarbear series 120W 160w LED Industrial flood light fitting waterproof IP66
Industrial Polarbear series LED flood light 120W 160W
Highlight: Industrial LED Flood light fixture
Features And Benefits:
1. High strength copper-free aluminum alloy housing plus strong tempered glass,IK08.
2. Osram/Lumileds LED Source, lamp efficacy up to 160lm/w, more than 50% energy saving than traditional HPS lighting sources.
3. Perfect heat sink design, with separated Led source compartment and Led driver compartment.
4. Designed with several beam angles for different applications, 120W is also available for street light beam angle.
5. 5KV Surge protection.
6. Low THD<10%, less interference.
7. Ambient temperature from -40℃ to 55℃.
8. 5 Years performance warranty.
Product Differentiation:
| Standards |
EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
| Certificate | CE, RoHS |
| Ambient temp | -40℃ ≤ Ta ≤ +55℃ |
| Ingress Protection | IP66 |
| Cable entry | M25*1.5(M20*1.5,3/4 NPT for optional) |
Applications:
KHJ Industrial LED Flood light Polarbear series can be widely used for:
Heavy Industries
Manufacturing plants
Warehouse
Workshops
Tunnels
Power stations
Ordering information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp. | CCT(K) |
| KPLB120*WM-E |
100-277 AC (141-392 DC) |
16380 | 120 | 70 | Warm white | 3000±300 |
| KPLB120*NH-E | 17640 | 120 | 70 | Natural white | 4000±300 | |
| KPLB120*NH-E | 17640 | 120 | 70 | Natural white | 5000±300 | |
| KPLB120*CH-E | 17640 | 120 | 70 | Cool white | 5700±300 | |
| KPLB160*WM-E | 21840 | 160 | 70 | Warm white | 3000±300 | |
| KPLB160*NH-E | 23520 | 160 | 70 | Natural white | 4000±300 | |
| KPLB160*NH-E | 23520 | 160 | 70 | Natural white | 5000±300 | |
| KPLB160*CH-E | 23520 | 160 | 70 | Cool white | 5700±300 |
Remarks:;
1. * Stands for beam angle,including H1V1 / H4V4 / H5V5 / H6V6 / SL/FW;
2. For Beam angle H1V1,H4V4 and H5V5,the luminous flux will be 15% less;For Beam angle FW/SL,the luminous flux will be 30% less;
3. SL beam angle is only applicable for 120W.
