AR Coating Optical Glass Windows 300mm Fine Ground Uv Fused Silica Window

Offered Fused Silica AR Coating Laser Protective Windows, Laser Protective Windows φ5-300mm

offers laser protection window for applications which require protecting laser output. High damage threshold (>15J/cm2) AR coating on both sides can minimize the reflections.These windows are used in front of lasers for material processing in order to protect the laser optics from hot material drops.

UV Fused Silica High-Precision Windows are available in four sizes ranging from Ø1/2" to Ø2" and a rectangular 25 mm x 36 mm size. Round windows can be purchased from stock uncoated (185 nm - 2.1 μm) or with one of our four low-loss standard broadband antireflection coatings deposited on both surfaces: -UV (245 - 400 nm), -A (350 - 700 nm), -B (650 - 1050 nm), or -C (1050 - 1700 nm). While uncoated windows have typical losses of about 4% per surface, the AR coatings reduce this to Ravg < 0.5%. These AR coatings provide good performance for angles of incidence (AOI) between 0° and 30°.

Attention

offers flat windows fabricated from N-BK7, UV Fused Silica, Sapphire, Calcium Fluoride, Magnesium Fluoride, Potassium Bromide, Infrasil, Zinc Selenide, Silicon, Germanium, or Barium Fluoride. Our laser windows have a wavelength-specific AR coating centered around commonly used laser wavelengths and an optional wedge, while our precision windows are offered with or without a broadband AR coating. For more information on these substrates,

Map Optics Technology provides a variety of flat Windows with no coating and anti-reflection coating substrates.

Parameters

Processing capacity

We offer more transportation options

FAQ
