Electric Scooter Hailong Ebike Battery Pack 48V 10Ah Long Cycle Life
Electric Scooter Hailong Ebike Battery Pack 48V 10Ah Long Cycle Life
Electric Scooter Battery 48V 10AH Lithium ion Electric Bike Battery Pack
Note: The battery discharge port defaults to T plug or XT60 or XT90. If you need to customize other discharge plugs, please contact customer service or remarks at the time of purchase
Description:
|
General Information |
|
|
Nominal Voltage |
48V |
|
Battery construction |
13S5P |
|
Cell |
18650*65PCS |
|
Storage Temperature |
-20℃~45℃ |
|
Operating Temperature |
-20℃~60℃ |
|
Continuous Charge Current(Max) |
5A(customized) |
|
Continuous Discharge Current(Max) |
30A(customized) |
|
Cycle time: |
1000 times |
|
Charging Time |
4-6 hrs |
|
Dimension |
370*110*90mm |
|
Weight: |
5.5KG |
1. Battery Model: 36V 10Ah
Life cycle: 1000 times (80% DOD)
Net Weight: About 3.4kg
Dimension: 370*90*90mm
Discharge Cutoff Voltage: 28+/- 1V
Charge Cutoff Voltage: 42V
Instantaneous Maximum Discharge Current: 80A
Maximum Continuous Discharge Current: 30A
Charging temperature: 0-45°C
Discharge temperature: -20~60℃
Power: 250W-1000W
BMS Protection Function: Over charge, Over discharge, Over current, Short circuit protection, Balance
Product Features:
-
• High energy density Volume energy density can be 460Wh/L
-
• Long cycle life-capacity recovery can be above 80% after 500cycles
-
• Safety-No fire, no explore of short-circuit, over-charge, over-discharge, over-current, Shock, vibration, crush, acupuncture.
-
• Superior storage characteristics-The self-discharge rate of Lithium-ion polymer battery is about 3% per month when stored at room temperature
-
• Various Products-Hundreds of moulds from micro size10mAh to large capacity 10000mAh
Advantages:
-
• Technology-With more than 20 years of battery manufacturing and automatic production line, We can guarantee our products better products.
-
• R&D-Experienced R&D team with over 20 engineers for supporting OEM and ODM requirements
-
• Safety-Various tests are done at GPE to ensure the safety of our products for our customers.
-
• Certificates-CE, RoHs, BIS, KC, UL, MSDS, UN38.3, IEC61233 certificated.
-
• Service- a professional sales team to provide professional project solutions and after-sale services.
Company profile:
-
Our company was established in 1994, more than 20 years experience as a battery solution provider
Our lithium battery, main used in Digital Electronic products, IOT device, Medical care, Wearable device, GPS, POS device, Power tools and Light Electric Vehicles etc.
Certified: ISO9001, and all products comply with the RoHS,UL,CE,CB,PSE,KC,IEC62133 and BIS.
Widely application:
Home Appliance, IOT, Digital Products, Communication unit, Medical Device,Portable Devices, Beauty equipment etc.
Golf cart , E-scooter, E-mobility, E-motorcycle, E-tricycle, etc.
