DJL China Made Freezer Food Processing Machine Stainless Steel Belt IQF Tunnel Freezer
product description
Food quick freezing is a food freezing technology that puts the processed food in a low-temperature device, passes through the maximum ice crystal growth zone within 30 minutes, the central temperature drops below - 5 ° C, the diameter of the ice crystal formed is less than 100 microns, and the central temperature of the food after quick freezing must reach below - 18 ° C.
| Equipment material: | SUS304 stainless steel |
| Working temperature: | -150℃~room temperature |
| Temperature control precision: | ±2℃ |
| Temperature uniformity: | ±5℃ |
| Cooling rate: | ≥20℃/min |
| Heating rate: | ≥5℃/min |
| Distribution specification: | 380V/50HZ |
Specification
|
Model
|
Tunnel length
(mm)
|
Wire belt width
(mm)
|
Tunnel height
(mm)
|
Power
(KW)
|
freezing capacity
(kg/h)
|
|
DJL-QFL-1206
|
6000
|
1200
|
1750
|
10
|
400-600
|
|
DJL-QFL-1209
|
9000
|
1200
|
1750
|
12
|
800-1000
|
|
DJL-QFL-1212
|
12000
|
1200
|
1750
|
18
|
1000-1200
|
|
DJL-QFL-1609
|
9000
|
1600
|
1750
|
15
|
1000-1200
|
|
DJL-QFL-1612
|
12000
|
1600
|
1750
|
28
|
1800-2100
|
|
DJL-QFL-1618
|
18000
|
1600
|
1750
|
32
|
2000-2500
|
|
DJL-QFL-1815
|
15000
|
1800
|
1750
|
28
|
2000-2500
|
|
DJL-QFL-1818
|
18000
|
1800
|
1750
|
32
|
2200-2800
|
|
DJL-QFL-1824
|
24000
|
1800
|
1750
|
46
|
2800-3500
|
FAQ
1. What are your main products? In which areas?
Our products are of many types and specifications, such as the cabinet type, box type and tunnel type, etc. These series products have been widely used in many domestic and foreign areas, such as the food processing, mechanical engineering, genetic engineering, precision electronic, medical research, plant conservation, aerospace and rear livestock, etc.
2. What certificate do you have?
Passed the ISO9001 Management System Certification in 2019.
3. How to send the equipment to my country?
By sea, using 20'GP, 40'GP or 45'GP containers, depends on size of the equipment.
4. How much liquid nitrogen will be consumed for freezing foods?
Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.
