PBT Bar 1.25mm Pitch Wafer Box Connector Brass Contact 2 Pin Female Header
Price:
Negotiable price
MOQ:
1500pcs
Delivery Time:
5-7 days
Brand:
XTKCONN
Product Description
PBT Bar 1.25mm Pitch Wafer Box Connector , Brass Contact 2 Pin Female Header
Product Description
| Mounting Type | DIP Type |
| Pitch | 1.25mm |
| No. Of Positions | 2-15p |
| Rated current | 1.0A AC |
| Rated voltage | 125V AC/DC |
| Contact Resistance | 20m ohms MAX |
| Insulation Resistance | 100m ohms min |
| Insertion Force | 20gf/pin Min |
| Operation Temperature | -25℃ to +85℃ |
| Withstanding Voltage | 500V/1min AC |
| Housing | LCP UL94V-0 |
| Contact | Brass Tin-plated |
| Gender | Female |
| Price Term | FOB |
| Durability cycles | 5000 Cycles Min |
| Lead Time | 7-10 working Days |
Drawing
Exposure length
The length of the electrical contact that has been exposed at the termination of the cable.
- Conductors size
- The width and thickness of the conductors
Now the FFC Cables are widely used in a variety of printer connection between the head and the motherboard, plotters, scanners, copiers, stereos, LCD appliances, fax machines, DVD players and other products, a variety of signal transmission and plate board connections. In modern electrical equipment, FFC Cables can be found almost everywhere.
Equipment and Service
27 automated infection molding,20 automated pin-setting and 16 high-precision stamping machines
prefessional and patient pre-service & after-service
professsional sales team & engineering team & techinology team
puntual delivery time and complete packaging process
preferable price and best quality.
