Simplex Fiber Optic Patch Cord Jumper FTTH Drop Cable
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
Negotiable
Brand:
XDK
Product Description
Simplex Fiber Optic Patch Cord Jumper FTTH Drop Cable
Features
- 100% connectors tested ; - Insertion Loss(SM): Typical<0.2dB, Max<0.3dB ;
- Deliery 100% passed products ; - Return Loss: UPC>50dB, APC>60dB ;
- High reliability ; - Repeatability: >1000 times ;
- CE & RoHS compliant ; - Lifetime Warranty
| Item | vaule |
| Ferrule end-face | PC UPC APC |
| Connector type | FC,SC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4 and SMA |
| Cable type | SX/LSZH |
| Mode | SM:9/125 |
| Cable diameter | 2.0mm,3.0mm |
| Insertion loss | ≤0.2 and ≤0.3dB |
| Return loss | ≥50 and ≥65dB |
| Exchangeability | ≤0.2dB |
| Vibration | ≤0.2dB |
| Operating temperature | -40 to 75 |
| Storage temperature | -45 to 85 |
| Tensile force | 50N/static state 30N/used state |
