MPO / MTP OM3 12 Core Multi Mode Fiber Optic Patch Cord for Data Center
Price:
negotiation
MOQ:
negotiation
Delivery Time:
Negotiable
Brand:
XDK
Product Description
MPO / MTP OM3 12 Core Multi Mode Fiber Optic Patch Cord for Data Center
Features
1.High reliability ;
2.CE & RoHS compliant ;
3.100% connectors tested ;
4.Repeatability: >1000 times ;
5.Deliery 100% passed products ;
6.Insertion Loss(SM): Typical<0.2dB, Max<0.3dB ;
7.Return Loss: UPC>50dB, APC>60dB ;
Parameters
Single mode (9/125)
Max Insertion Loss: 0.3dB
Minimum Return Loss: PC: 50dB APC: 60dB
Multi mode(50/125, 62.5/125, OM3)
Max Insertion Loss: 0.5dB
Minimum Return Loss: 25dB
Operating temperature: -40 to +75
Storage temperature: -40° C ~ +80° C
| Characteristic | SM , MM | |||
| Connector type | FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000 | |||
| Diameter(mm) | 0.9,2.0,3.0 | |||
| Polishing grade | SM UPC | MM UPC | SM APC | |
| Insertion loss | Grade B | ≤0.15dB | ≤0.1dB | ≤0.15dB |
| Grade C | ≤0.30dB | ≤0.30dB | ≤0.30dB | |
| Return loss | ≥55dB | ≥30dB | ≥65dB | |
| Interchangeability | ≤0.1dB | |||
| Repeatability | ≤0.1dB | |||
| Operation temperature (ºC) | -20°C ~ +70°C | |||
| Storage temperature (ºC) | -40°C ~ +80°C | |||
