Acetek Hybrid Flatbed Printers 1.8m Width CE ISO9001 Certificated
Price:
USD11500/1set-USD1200/1set
MOQ:
1 set
Delivery Time:
5-7 working days
Brand:
Acetek
Product Description
Acetek V-180E high quality 1.8m width uv hybrid printer with epson xp600/dx5 print head
why we chose our V-180E uv hybrid printer machine?
1. one machine can be eco solvent UV flatbed printer or uv flatbed printer
2. one machine can be flatbed or roll to roll
3. comparing to other brand UV flatbed printer,our Acetek machine is very competitive
4. easy to install, you just know how to install head, we have professional engineer to guid you
on the line.
5. machine's stability, our all the machine will be tested before we delivery to our customer.
Parements of 1.8m uv hybrid printer with epson xp600 head
| Model | ACETEK roll to roll flatbed hybrib UV printer V180E | |
| printhead | Piezo Electric Printhead DX5/xp600 | |
| Number of Printhead | or 4pcs heads DX5/xp600, | |
| Max Print Width | 1800mm(74”) | |
| Printing Resolution | 4Pass | 30 m²/hr |
| 6Pass | 20 m2/hr | |
| 8Pass | 15 m2/hr | |
| 16Pass | 7 m2/hr | |
| Ink | Type | Eco solvent ink, UV ink |
| Color | 4/6/8 color | |
| Capacity | 0.25L | |
| Ink Supply System | Block brake type of ink supply system | |
| Media | Width | 1800mm(74”) |
| Type | PVC, PP, Soft materials, Textiles, PVC Board, Hollow board, Metal, Wall paper, Leather, Glass, Fabric, Acrylic, KT board, Chevron board etc | |
| Print Height | 10-30 mm above media adjustable | |
| Heating System | pre-heating platen-heating post-heating | |
| Media adsorption system | Several phase of intelligent air draft, and intensity adjustable | |
| Media adsorption | Independent intelligent air suction system with 3 sections control | |
| Auto Printhead Cleaning System | Auto cleaning system with Anti-clogged Flash Function & Moisturing System | |
| Clamp | Equipped | |
| Auto take up system | Selectable | |
| Print Interface | HI-USB2.0/ 3.0 | |
| RIP software | Maintop,Photoprint,Wasatch | |
| Input Power | AC220V,50Hz/60Hz | |
| Working environment | Temperature 18-31°C | |
| Humidity: 46-65%Rh | ||
| Machine Dimension | Appearance size(L*W*H)3160*1130*1330 | |
| Packing Dimension | Pakage size(L*W*H)3350*800*1500 650kgs ±15kg | |
