50W UV LED 365nm 395nm PCB Uv Led Lamp for Uv Dryer Uv Led Curing System with Fan Cooling for Screen Printing LED UV Curing
Product Advantages
1. In terms of spraying: ordinary phone case spraying, cosmetic case spraying, Plastic spraying of MP3 small
household appliance shells and other materials
2. Printing: Screen printing, offset printing, 5-color printing, etc. Use UV curing lamps to dry UV ink.
3. In the footwear industry, it is the use of ultraviolet radiation to illuminate the material on the sole of the shoe,
causing a chemical reaction and creating a good affinity between the adhesive and the sole and upper.
4. In terms of wood industry, it is used for curing UV paint coatings on the surface. Due to the excellent performance
of UV coatings (such as varnish) in various aspects, such as wear resistance, friction resistance, acid and alkali resistance,
weather resistance, etc.
5. Crafts polishing: As long as the surface of handicrafts is processed using UV polishing oil, UV lamps can be used.
36W UV Led Module Product Description
| Product Name |
YM-K5-5020 UV LED Module |
| Power | 50W |
| Color | UV |
| Number of lamp beads | 5 pcs |
| Diode type | 6565 smd |
| Lens Material of Diode | Quartz |
| View Angle of the Lens | 60, 120 degree |
| Module size | 50mm*20mm*2mm |
| Luminous Size | 50mm*7mm |
| Wavelength | 365nm,385nm,395nm,405nm |
| Voltage | 32.5-37.5V |
| Current | 1-1.4A |
| Chip Material | Seoul,LG,Epileds |
| Encapsulation process | High temperature quartz lens package module lamp |
| Module material | 2.0mm Copper substrate |
| Lifespan (hours) | 15000 |
| Warranty | 1 year |
| Application | Apply in various UV printing industries, painting,UV inks, UV glues, and touch screens. |
| Place of Origin | Shenzhen, Guangdong, China |
UV LED curing light source products, and produces hundreds of high-power UV LED light packaging
products. The product power range is from 0.5W to 10000W. Mainly used for flexographic printing
machines, printing machines, pad printing machines, screen printing machines, offset printing machines,
coating machines, exposure machine, inkjet printing machine, coating, leather, glass, metal, furniture,
car paint detection, fluorescence detection, pet urine detection,PCB and other UVink Photocuring.
Our UV LED curing systems are widly used in glass industry, decoration industry, building materials industry,
furniture industry, etc.
It's suitable for kinds brand of inkjet sprayers such as Konika,Xaar, Ricoh, and kinds of printers
includingflatbed printer, roll to roll printer, wide format printer, inkjet, digital printer, rotary press etc.
FAQ
Q1.What's your LED chip?
A: We use are Korea LG, Seoul, Taiwna Epileds about the LED chip brand
Q2. What’s the lifespan of UV LED?
A: The lifespan of the LED chip is 20,000 hours in theory. If you take care it during the usage, it usually can be used 3-5years.
Q3. What’s the warranty?
A: All of products can warranty for one year, if any parts damaged in warranty, we can supply the parts for free, but you need send back the UV LED lamp and power supply or water chiller, other parts no need send back.
Q4. Can we customize the product?
A:Yes! We can producing the products according to your requirements
Q5. What is your usual payment terms for orders?
A:FOREIGN TRADE PLATFORM. T/T, PAYPAL, WESTERN UNION, BANK TRANSFER VISA/MASTERCARD etc. More payment terms could be provided.
If you have other needs, please contact us to provide you with the best solution.
Umi@ymleduv.com , Thank you for your attention.
