H Type Layer Chicken Cage System: 3/4 Tier Battery Cage For Egg Production With Automatic Feeding & Egg Collection, Galvanized Steel
Our H Type Layer Cage System is designed for commercial layer farms and intensive egg production projects. Featuring a multi-tier cage structure, this H type battery cage system helps maximize poultry house space utilization and supports efficient daily management of laying hens.
Available in multiple cage sizes, the system can be configured according to flock capacity, poultry house dimensions, and farm automation requirements. It can be integrated with automatic feeding, nipple drinking, egg collection, and manure removal systems to reduce manual labor and improve operational efficiency.
As a professional poultry equipment manufacturer, we provide customized layer cage solutions for small, medium, and large-scale commercial poultry farms.
| Parameter | Specification |
|---|---|
| Cage Depth | 625 mm |
| Cage Height | 500 mm |
| Cage Length | 650 mm |
| Each Floor Distance | 650 mm |
| Birds per Cell | 9 birds |
| Capacity per Set | 72 birds |
| Space per Bird | 450 cm²/bird |
| Parameter | Specification |
|---|---|
| Cage Depth | 625 mm |
| Cage Height | 500 mm |
| Cage Length | 1000 mm |
| Each Floor Distance | 650 mm |
| Birds per Cell | 7 birds |
| Capacity per Set | 112 birds |
| Space per Bird | 446 cm²/bird |
| Parameter | Specification |
|---|---|
| Cage Depth | 540 mm |
| Cage Height | 500 mm |
| Cage Length | 1000 mm |
| Each Floor Distance | 650 mm |
| Birds per Cell | 6 birds |
| Capacity per Set | 96 birds |
| Space per Bird | 450 cm²/bird |
Note: The specifications above are based on the supplied models. Please confirm the final cage configuration and dimensions before ordering.
The H-frame design uses vertical space efficiently, making it suitable for commercial poultry houses that require organized cage layouts and high production capacity.
The cage system can be manufactured with galvanized steel components to provide corrosion resistance and durability in poultry house environments. Hot-dip galvanized options are available according to project requirements.
Three cage specifications are available to accommodate different cage layouts and bird capacities. Customers can select a suitable model based on the planned flock size, poultry house dimensions, and management requirements.
An automatic feeding system can be integrated with the H type layer cage to distribute feed along the cage rows, helping reduce manual feeding work and improve daily farm management.
The nipple drinking system provides convenient access to drinking water for laying hens. Water supply components can be configured according to the farm's requirements.
An automatic egg collection system can transport eggs from the cage rows to the collection area, reducing manual handling and improving egg collection efficiency.
Manure belts can be installed beneath the cage tiers to remove poultry manure from the house more efficiently, helping simplify cleaning and daily maintenance.
For modern commercial layer farms, the H type layer cage system can be combined with:
- H type layer chicken cages
- Automatic feeding equipment
- Automatic nipple drinking equipment
- Egg collection conveyors
- Manure removal belts
- Feed silos and feed conveying systems
- Ventilation fans and cooling pads
- Environmental control systems
The equipment configuration can be customized according to the project scale, poultry house layout, and desired level of automation.
Our H type layer cage system is suitable for:
- Commercial layer chicken farms
- Large-scale egg production facilities
- Intensive poultry farming projects
- Closed-house layer farms
- New poultry farm construction
- Existing farm expansion and upgrading
- Automated poultry production systems
- Professional poultry equipment manufacturer
- More than 30 years of manufacturing experience
- Multiple cage specifications available
- Galvanized steel construction options
- Automatic feeding and drinking systems available
- Optional automatic egg collection and manure removal
- Customized poultry house equipment solutions
- Technical installation guidance and after-sales support
Henan Silver Star Poultry Equipment Co., Ltd. specializes in poultry farming equipment and complete poultry farm solutions. Our main products include H type layer cages, A type layer cages, broiler cages, automatic feeding systems, drinking systems, egg collection equipment, and manure removal systems.
We can provide a basic poultry house layout based on your planned bird capacity and house dimensions, helping you select suitable cage specifications and equipment configurations for your project.
An H type layer cage system is a multi-tier poultry housing system designed for commercial egg production. It makes efficient use of poultry house space and can be equipped with automatic feeding, nipple drinking, egg collection, and manure removal systems.
We offer three models: 650 × 1250, 1000 × 1250, and 1000 × 1080. The capacities are 72, 112, and 96 birds per set, respectively. Please contact us to confirm the configuration suitable for your poultry farm.
Yes. The H type layer cage can be integrated with automatic feeding, nipple drinking, egg collection, and manure removal systems. The equipment configuration can be customized according to your farm size and automation requirements.
The cage system can be manufactured using galvanized steel components to provide corrosion resistance and durability in poultry house environments. Hot-dip galvanized options are available depending on the selected configuration.
Yes. We can recommend a suitable H type layer cage configuration based on your planned number of laying hens and poultry house dimensions. We also provide basic poultry house layout planning, equipment quotations, and technical installation guidance.
