BDA446 Bluetooth Dynamic Attitude Sensor with 9-Axis IMU for Industrial Motion Monitoring
Price:
$80.00/Pieces
MOQ:
1
Delivery Time:
5~8 work days
Brand:
RION
Product Description
● PRODUCT DESCRIPTION
BDA446 is a high cost-effective Bluetooth output dynamic attitude sensor that can be widely used in equipment that requires high dynamic balance, such as model aircraft, robots, agricultural machinery, construction vehicles, forklifts, etc. This device collects data from sensors, integrates Kalman filtering, and outputs real-time attitude data. Due to the use of three-axis accelerometer and three-axis magnetic sensors to assist three-axis gyroscopes and temperature compensation algorithm technology, the product achieves excellent stability and real-time performance in all attitudes, and is widely used in various motion attitude monitoring fields. This product not only outputs attitude data, but also three-axis acceleration, three-axis gyroscope and other data. At the same time, it can modify and expand system operating parameters, suitable for various application platforms. This product adopts Bluetooth wireless output, Bluetooth 5.1 wireless transmission module, and BLE protocol. Integrated 2.4GHz
adaptive frequency hopping technology enables 40 meter line of sight transmission (unobstructed environment) and BLE DFU Bluetooth wireless firmware upgrade, significantly improving the flexibility of industrial field deployment.
● MAIN FEATURES
★ Integrated nine axis sensor and temperature sensor
★ Low noise
★ Bluetooth 5.1 wireless transmission
★ Kalman filtering algorithm
★ DC 3.0-4.2V battery power supply
★ Real time 3D dynamic measurement
★ Maximum update rate of 100Hz
★ High performance drift stability
★ Long lifespan, strong stability
● APPLICATION FIELD
★ Cranes and construction machinery
★ Mobile machinery
★ Agricultural machinery
★ Mobile elevators and fire trucks
★ Elevated platforms
★ Robot applications
★ Automatic Guided Vehicles (AGV)
★ Automatic assembly machinery
★ Boring and drilling applications
★ Leveling and flattening
