China DMI810/DMI820 High Precision Digital Inclinometer with <0.005° Accuracy and 64 True Colors Night Vision Display for Dual Axis Angle Measurement for sale

DMI810/DMI820 High Precision Digital Inclinometer with <0.005° Accuracy and 64 True Colors Night Vision Display for Dual Axis Angle Measurement

Price Negotiable

Price: $438.00/Pieces

MOQ: 1 Pieces

Delivery Time: 5 days for samples

Brand: RION

Product Description

▶ GENERAL DESCRIPTION

DMI810/DMI820 is a digital display inclinometer which took RION company three years to develop professional for various industry angle controling and measuring.The core of this product is using the micro-mechanical control principle, dual-core measurement unit, can use the Y-axis to compensate X-axis during the measurement process,and then to use RION patent interleaved and temperature compensation model algorithm to play absolute operation advantages of the micro-mechanical electronic principles,to ensure that the instruments measurement with the long-term stability and repeatability. Single and double axis measurement, measurement range ±30° measurement, resolution 0.001°, highest accuracy <0.005° full value,fast response, stable data, products specially designed for the sides and bottom with magnetic adsorption installation, both sides of the benchmark can be measured and using normally,very convenient to use, DMI810 series has strong scalability, convenient & practical application and industrial reliability, has absolute cost advantage and has an absolute competitive advantage in the international market !

▶ FEATURES

★ Best accuracy: <0.005°

★ Repeatability: 0.003°

★ Angle resolution: 0.001°

★ Maximum measure range: ±30°

★ User can set the alarm value by himself

★ Absolute/Relative measurement can switch

★ Both sides and bottom can measure

★ Double benchmark strong magnet installation

★ Working Temperature : -10°～ +70℃

★ Auto-angle interleaved compensation function

★ Auto temperature drift compensation

★ User can calibrate ZERO by himself

★ Built-in rechargable industry batteries

★ Night vision fours colors screen

★ IP54 protection class

★ °/mm/m Dual units switch function

★ Three kinds of measurement mode selectable (radian, angle, mm)

▶ APPLICATION

★ Building construction

★ Automobile four-wheel testing

★ Road slope

★ Machinery installation

★ Piping installation

★ Industrial platform

★ Turntable testing

★ Pan unit angle detection

★ Production jig

Measuring Axis	Single Axis		Dual Axis			Axis
Angle Measuring Range	±15 °	±30 °		±15 °	±30 °	°
Angle Measurement Accuracy(Full Range)	<0.005	<0.01		<0.005	<0.01	°
Angle Measure Resolution	0.001	0.001		0.001	0.001	°
Mm/m Measure Range	267	577		267	577	mm/m
Mm/m Measure Accuracy	0.1	0.2		0.1	0.2	mm/m
Mm/m Measure Resolution	0.02	0.02		0.02	0.02	mm/m
Repeatability	0.003	0.003		0.003	0.003	°
Measurement Mode	Angle,Degree/Minute/Second,Mm/m Three modes can be set
Working Temperature	-10°~ +70℃
Working Humidity	85%RH
Power Supply	3.7V Charging Lithium Battery
Ideal Charging Time	5h
Battery Continuous Working Time	11h
Equipped With PC Software	VC Software
Data Output Signal	USB2.0 (Virtual Serial Device)
Connect Plug In	Standard USB Connector, Rechargeable
Shock Resistance	10g@11ms,3 Axial Direction (Half Sinusoid)
Shock Impact	10grms,10~100Hz
Waterproof Grade	IP54
Material	Aluminum Alloy Anodizing
LCD	64 True Colors Night Vision Display Screen
LCD Visible Area Size	L57.6*W43.2mm
Size	L109W77H27mm
Weight	≤350g
