AKF390 How Can a 3-Axis Vibration Sensor Improve Industrial Vibration Monitoring
APPLICATION
- Medical equipment
- Bridge
- Automobile
- Road roller
- Wind power generation
- Large machinery, engines
- Low-frequency vibration and automatic monitoring
- Traffic system monitoring, roadbed analysis and high-speed railway fault detection
MAIN FEATURE
- three axis (X/Y/Z)
- output voltage: 0~5V
- power supply: 9~36V
- excellent bias stability
- working temperature: -40℃ ~ +85℃
- store temperature: -40℃ ~ +85℃
- Good environmental performance (impact, vibration and temperature)
ACCELERATION CALCULATION FORMULA
Acceleration = (Output Voltage -2.5V) ÷ Sensitivity
The sensitivity can be obtained from the theoretical value
of the technical parameters or the actual test
E.g: AKF390-02-T (± 2G measurement range, 0 ~ 5V output voltage range)
Acceleration = (4-2.5)/1.25 = 1.2g
Note: Gravity 1G exists in the vertical direction in the static state.
| AKF390 | PARAMETER | UNIT | |||||
| Range | ±2 | ±4 | ±8 | ±10 | ±20 | ±40 | g |
| Deviation Calibration | <1 | <1 | <1 | <1 | <1 | <1 | mg |
| Measuring Axial | X,Y,Z | X,Y,Z | X,Y,Z | X,Y,Z | X,Y,Z | X,Y,Z | Axis |
| UP/Off Power Repeatability | <2 | <2 | <2 | <2 | <2 | <2 | mg(max) |
| Sensitivity (± 10%) | 1250 | 625 | 312.5 | 250 | 125 | 62.5 | mv/g |
| Deviation temp. coefficient | 0.01 | 0.01 | 0.01 | 0.05 | 0.05 | 0.05 | % /℃ |
| Resolution/Threshold (@ 1Hz) | < 1 | < 1 | < 1 | < 1 | < 1 | < 1 | mg(max) |
| Nonlinearity | <1 | <1 | <1 | <1 | <1 | <1 | % FS(max) |
| Frequency response | 500 | 500 | 500 | 500 | 500 | 500 | Hz |
| Bandwidth (3DB) | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | Hz |
| Cross-axis sensitivity | 1 | 1 | 1 | 2 | 2 | 2 | % |
| Lateral vibration sensitivity ratio | 1 | 1 | 2 | 5 | 5 | 5 | % |
| Resonance frequency | 2.4 | 2.4 | 2.4 | 5.5 | 5.5 | 5.5 | kHz |
| Noise density | 21 | 21 | 21 | 86.6 | 86.6 | 86.6 | μg/√Hz |
| 0g output 2.5V | <0.01 | <0.01 | <0.01 | <0.008 | <0.008 | <0.008 | mV |
| The output voltage | 0~5V | ||||||
| Input(Vdd_Vss) | 9~36 VDC | ||||||
| Current Consumption | <60mA @ 12 VDC | ||||||
| Connector | Industrial Standard M12 Connector | ||||||
| Protection grade | IP67 | ||||||
| Weight | Product net weight: 82g, magnetic base: 48g, L-shaped adapter plate 20g | ||||||
| Dimension | Product size: 34.3*34.3*38.5mm Magnetic adsorption base size: 34.23*34.23*8.1mm L-shaped adapter plate size: 36*44*15mm |
||||||
FAQ
Q1: What is the AKF390 3-axis vibration sensor?
The AKF390 is a triaxial MEMS capacitive vibration sensor with analog voltage output. It measures acceleration along the X, Y, and Z axes and is suitable for vibration testing, impact testing, and industrial monitoring applications.
Q2: What is the output voltage of the AKF390 vibration sensor?
The AKF390 provides a 0–5V analog voltage output for integration with compatible data acquisition systems, controllers, and monitoring equipment.
Q3: What is the power supply requirement of the AKF390?
The AKF390 operates with a DC power supply ranging from 9V to 36V, making it suitable for various industrial equipment and monitoring systems.
Q4: Can the AKF390 measure vibration in three directions?
Yes. The AKF390 measures acceleration along three axes: X, Y, and Z. This allows users to monitor vibration in multiple directions for equipment condition assessment and structural monitoring.
Q5: What is the operating temperature range of the AKF390?
The AKF390 operates at temperatures from -40°C to +85°C. Its design supports stable operation in a wide range of industrial environments.
