Precision Detection AI SWIR Sorter Machines PET Bottle Sorting Machine
Price:
Price Negotiable
MOQ:
1
Delivery Time:
5-8 work days
Brand:
PHOENIX
Product Description
HPB AI-SWIR SorterAI Powered Precision Detection By Color, Polymer, Label And Shape: Recovery Of PET Bottles And Other Plastic Bottles
Technical Features
- Technical Features
- Dual-Sensor Simultaneous Detection
- Superior InGaAs-SWIR Camera System detects polymer types (PET/HDPE/PP, etc.) based on molecular composition
- High-resolution RGB Camera System detects color variations (clear/blue/green/contaminated bottles)
- AI Deep Learning
- Automatically classifies bottles, caps, labels and contaminants (metal, silicone)
- Self-learning for new materials and complex patterns (e.g., printed-label bottles)
- Adapts to challenging scenarios (reflective/black/crushed bottles)
- High-Performance Belt Sorting
- Modular belt system: 2-6 tons/hour capacity
- 88-224 nozzles with ≤1ms response & ±2mm ejection accuracy
- Modular design of belt width from 1200 to 2800mm (1200/2000/2800) provides processors more flexibility
- Dual-Sensor Simultaneous Detection
Specifications
| Model | Belt Width (mm) | Air Nozzle | Throughput (t/h) | Air Pressure (MPa) | Air Consumption (m³/min) | Power (kW) | Unpacked Weight (kg) | Dimension (mm) |
|---|---|---|---|---|---|---|---|---|
| HPB1 | 1200 | 88 | 1.5~3.0 | 0.6~0.8 | <3.5 | 7 | 4000 | 9600×2000×2900 |
| HPB2 | 2000 | 160 | 3.0~4.0 | 0.6~0.8 | <6.5 | 12 | 5000 | 9600×3200×2900 |
| HPB3 | 2800 | 224 | 4.0~6.0 | 0.6~0.8 | <9.0 | 16 | 6500 | 9600×4000×2900 |
