600mm Belt Potato Grading Equipment For Fruits And Vegetables
Price:
Price Negotiable
MOQ:
1
Delivery Time:
5-8 work days
Brand:
PHOENIX
Product Description
HD AI Optical Sorter AI Powered High-precision Defect Removal And Quality Grading With Industry-leading Accuracy For Dehydrated Vegetables
Technical Features
- Tailored Superior Sorting Solution for Dehydrated Vegetables
- Compact dual-belt sorting system with quick-install and simultaneous resorting design
- Primary sorting occurs on higher-level belt and aggressively removes all potential defects (may include false rejects)
- Secondary sorting on lower-level belt receives rejects from primary sorting for false-reject recovery
- Optional innovative high-capacity 2-layer vibratory feeder evenly distributes dehydrated vegetables into a single layer to minimize overlapping
- Food-grade stainless steel structure complies with global food safety and hygiene standards
- Sealed scanning and control boxes provides machine with high-level dust protection
- Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
- Quick belt change for convenient routine maintenance and cleaning, meeting higher food safety and hygiene standards
- Modular design of belt width from 600 to 1200mm (600/1200) provides processors more flexibility
AI Powered 4-in-1 Multispectral Inspection System
- Proprietary AI Deep Learning algorithms continuously improve defect recognition based on new samples
- High-Resolution RGB Camera System
- High-Intensity LED Illumination System
- Optional InGaAs-SWIR Camera System
- Optional UV Fluorescence Camera System
- Marketing-leading precision detection to a wide range of defects of dehydrated vegetables by color, size, shape and texture features:
- Color Defects: Browning, discoloration, charred spots, mold, skin residues
- Shape Defects: Broken fragments, clumped pieces, deformed shapes, oversized, undersized
- Drying Defects: Uneven dehydration, sugar crystallization, rehydration stains
- Foreign Material Contamination: plastic/rubber fragments
- Biological Contamination: Microbial colonies
High-Performance Ejector System
- Engineered for enhanced durability, optimized speed and air consumption
- Accurate rejection and reliable performance at high-capacity sorting
- Significant reduction in false rejection rate and total cost of ownership
Specifications
| Model | Belt Width (mm) | Air Nozzle | Air Pressure (MPa) | Air Consumption (m³/min) | Voltage | Power (kW) | Dimension (mm) | Unpacked Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| HD2 | 600 | 256 | 0.6~0.8 | <2.0 | 220V~50/60Hz | 6.4 | 3641×1540×2804 | 1376 |
| HD4 | 1200 | 512 | 0.6~0.8 | <4.1 | 220V~50/60Hz | 7.9 | 3641×2140×2804 | 1917 |
