SWIR Polymer Sorter AI Powered Precision Color Sorting Equipment
Price:
Price Negotiable
MOQ:
1
Delivery Time:
5-8 work days
Brand:
PHOENIX
Product Description
HPB AI-SWIR Sorter AI Powered Precision Detection By Color, Polymer, Label And Shape; Recovery Of PET Bottles And Other Plastic Bottles
HPB AI-SWIR Sorter is a superior AI powered sorting solution designed for recycling plants (PET bottle lines) and waste sorting centers (MSW processing plants) to use advanced color and polymer detection to automatically separate PET, HDPE, and other plastics with 99%+ accuracy for efficient recycling
Technical Features
- Dual-Sensor Simultaneous Detection
- Superior InGaAs-SWIR Camera System detects polymer types (PET/HDPE/PP, etc.) based on molecular composition
- High-resolution RGB Camera System detects color variations (clear/blue/green/contaminated bottles)
- AI Deep Learning
- Automatically classifies bottles, caps, labels and contaminants (metal, silicone)
- Self-learning for new materials and complex patterns (e.g., printed-label bottles)
- Adapts to challenging scenarios (reflective/black/crushed bottles)
- High-Performance Belt Sorting
- Modular belt system: 2-6 tons/hour capacity
- 88-224 nozzles with ≤1ms response & ±2mm ejection accuracy
- Modular design of belt width from 1200 to 2800mm (1200/2000/2800) provides processors more flexibility
Specifications
| Model | Belt Width (mm) | Air Nozzle | Throughput (t/h) | Air Pressure (MPa) | Air Consumption (m³/min) | Power (kW) | Unpacked Weight (kg) | Dimension (mm) |
|---|---|---|---|---|---|---|---|---|
| HPB1 | 1200 | 88 | 1.5~3.0 | 0.6~0.8 | <3.5 | 7 | 4000 | 9600×2000×2900 |
| HPB2 | 2000 | 160 | 3.0~4.0 | 0.6~0.8 | <6.5 | 12 | 5000 | 9600×3200×2900 |
| HPB3 | 2800 | 224 | 4.0~6.0 | 0.6~0.8 | <9.0 | 16 | 6500 | 9600×4000×2900 |
