Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum
-
High-Resolution RGB Camera System
Precise detection to non-ferrous metals (e.g., copper, aluminum, zinc) according to color, size, shape, thickness and texture differences
-
Proprietary AI Deep Learning Algorithms
Innovative simulation of manual picking operation by teaching and training the intelligent RGB sorter all the standards and features of identification and sorting
-
High-Intensity LED Illumination System
Enhanced identification of surface characteristics and features of targeting non-ferrous metal fractions, minimizing false rejects
-
Reliable High-Performance Ejector System
High-speed and powerful air ejectors designed and produced in-house ensure accurate rejection and reliable performance at high-capacity sorting
-
Versatility and Fast ROI
One machine handles a variety of scenarios and payback in 6-18 months by non-ferrous metal scraps recovery
-
Metal Recycling Plants: Reduce smelting impurities & energy consumption
- Extract copper/aluminum from mixed scraps (copper, aluminum, zinc, stainless steel) with efficiency and high purity
-
Auto Dismantlers: Improves recovery rates and profitability
- Extract high-value copper wires from shredder residue to boost profit per ton, distinguishing copper (reddish-brown) from aluminum (silver-white)
-
Battery Recyclers: Avoids hydrometallurgy risks
- Recover high-value electrode by detection to copper (purple-red) and aluminum (silver-white), targeting unpeeled areas
-
E-Waste Processors: Boost revenue, cut labor cost and reduce landfill waste
- Extract gold-plated contacts from discarded mobile phone boards to increase refining profits
-
Appliance Recycling: Purely physical sorting, no burning/chemicals
- Sort copper tubes (reddish-brown) and aluminum heat sinks (silver-white) from refrigerators/AC units
- Separate copper windings (shiny)from silicon steel (matte) in washing machine motors mix
| Model | Belt Width (mm) | Air Nozzle | Air Pressure (MPa) | Air Consumption (m³/min) | Voltage | Power (kW) | Dimension (mm) | Unpacked Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| HDF2-R | 600 | 256 | 0.6~0.8 | <2.1 | 220V~ 50/60Hz | 6.6 | 4686×1924×2685 | 1589 |
| HDF4-R | 1200 | 512 | 0.6~0.8 | <4.1 | 220V~ 50/60Hz | 8.3 | 5087×2524×2685 | 2165 |
| HDF6-R | 1800 | 768 | 0.6~0.8 | <4.1 | 220V~ 50/60Hz | 11.8 | 4998×2963×2685 | 2419 |
