Fresh Vegetable Sorter HDF AI RGB Color Sorter 220V-50/60Hz

Price Negotiable
Price: Price Negotiable
MOQ: 1
Delivery Time: 5-8 work days
Brand: PHOENIX
Product Description
HDF AI-RGB Sorter

AI-Powered & Custom-Tailored for Fresh Produce Sorting; Engineered for High-Pressure Washing & Sterilization

Technical Features
  • Compact dual-belt sorting system: Quick to install, with simultaneous re-sorting capability. Primary sorting occurs on the upper belt (aggressively removing all potential defects, including false rejects), while the lower belt receives false rejects from primary sorting for recovery.
  • High-capacity waterproof vibratory feeder: Evenly spreads fresh produce into a single layer to minimize overlapping.
  • Reinforced food-grade stainless steel structure + sealed scanning/control boxes: Withstands frequent high-pressure washing and sterilization.
  • Quick belt change design: Facilitates routine maintenance and cleaning, meeting elevated food safety and hygiene standards.
  • Field-proven Humidity Control System: Maintains consistent performance and reduces downtime.
  • Modular belt width options (600/1200/1800mm): Offers greater flexibility for processors.
AI-Powered 4-in-1 Inspection System
  • Proprietary AI deep learning algorithm: Continuously enhances defect recognition accuracy using new sample data.
  • High-resolution RGB camera system
  • High-intensity LED illumination system
  • Industry-leading precision in detecting a wide range of fresh produce defects across color, size, shape, and texture:
    • Color defects: Discoloration, mold, rot
    • Shape defects: Misshapen, deformed, oversized/undersized, broken
    • Surface damage: Bruises, cuts, abrasions, crushing, scars, cracks, shriveling
    • Biological contaminants: Insect damage, leaf/stem residues, produce debris, soil clumps
    • Foreign materials: Stones, plastic/rubber fragments, wood chips





Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HDF2 600 256 0.6~0.8 <2.1 220V~50/60Hz 6.6 4686×1924×2685 1589
HDF4 1200 512 0.6~0.8 <4.1 220V~50/60Hz 8.3 5087×2524×2685 2165
HDF6 1800 768 0.6~0.8 <4.1 220V~50/60Hz 11.8 4990×2963×2685 2419
