1200mm Belt Color Sorter QC Inspection Colour Sorter Machine

Price Negotiable
Price: Price Negotiable
MOQ: 1
Delivery Time: 5-8 work days
Brand: PHOENIX
Product Description
AI Quality Inspection Machine: Post-Regular Sorting, Smart-Driven Ultimate Quality Control, Replacing Traditional Manual Inspection
Technical Features
  • Tailored "Ultimate Quality Guardian" for dehydrated vegetables
  • Compact single-belt sorting system with quick-install design
  • Innovative high-capacity 3-layer vibratory feeder, which evenly spreads dehydrated vegetables into a single layer to significantly reduce material overlap
  • Food-grade stainless steel structure, compliant with global food safety and hygiene standards
  • Sealed scanning and control boxes, providing high-level dust protection for the machine
  • Quick belt change design, facilitating routine maintenance and cleaning to meet higher food safety and hygiene requirements
  • Integrated field-proven Dust Control System, ensuring operational stability and performance consistency while significantly reducing downtime risks
AI-Powered 4-in-1 Multispectral Inspection System
  • Proprietary AI deep learning algorithm, which continuously optimizes defect recognition capabilities based on new samples
  • Ultra-high-resolution RGB camera system
  • High-intensity LED illumination system
  • Optional NIR camera system or HSI camera system

Ultra-high-precision detection of subtle contaminants in dehydrated vegetables; identifies impurities with abnormal features (color, size, shape, texture), including:

  • Hair
  • Fibers
  • Low-density plastics
High-Performance Rejection System
  • Optional Air Nozzle Rejection System and Drop Flap Rejection System
  • Engineered with zero-tolerance rejection design, enabling reliable operation to achieve "ultimate quality control" objectives















Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
 QC4 1200 256 0.6~0.8 <3.6 220V~50/60Hz 3.9 4102*2443*2125 1097
