VG Intelligent Optical Sorter: AI-based Multispectral Recognition Of Fava Beans By Color, Size, Shape, And Texture Defects
Price:
Price Negotiable
MOQ:
1
Delivery Time:
5-8 work days
Brand:
PHOENIX
Product Description
VG Intelligent Optical Sorter Product Overview
The VG Intelligent Optical Sorter employs an AI-driven RGB/MSI smart camera module to achieve multi-dimensional defect recognition of fava beans based on color, size, shape, and texture characteristics. The self-developed deep learning algorithm supports continuous iterative optimization with new samples, steadily improving defect recognition accuracy.
Specifications
| Model | Chute | Air Nozzle | Air Pressure (MPa) | Air Consumption (L/min) | Power (kW) | Voltage | Dimension (LWH)(mm) | Weight*(kg) |
|---|---|---|---|---|---|---|---|---|
| VG1 | 1 | 64 | 0.6~0.8 | <1000 | 0.9 | 220V~ 50/60Hz | 1255*2199*2076 | 680 |
| VG4 | 4 | 256 | 0.6~0.8 | <2000 | 2.9 | 220V~ 50/60Hz | 2170*2199*2076 | 1150 |
| VG6 | 6 | 384 | 0.6~0.8 | <3000 | 4.4 | 220V~ 50/60Hz | 2800*2199*2076 | 1480 |
| VG8 | 8 | 512 | 0.6~0.8 | <4000 | 5.9 | 220V~ 50/60Hz | 3430*2199*2076 | 1840 |
| VG10 | 10 | 640 | 0.6~0.8 | <5000 | 7.3 | 220V~ 50/60Hz | 4070*2199*2076 | 2180 |
| VG12 | 12 | 768 | 0.6~0.8 | <6000 | 8.8 | 220V~ 50/60Hz | 4835*2199*2076 | 2550 |
Technical Features
I. Customized Sorting Solution for Fava Beans
- High-efficiency vibratory feeder – ensures a single-layer, uniform distribution of fava beans, effectively reducing material overlap.
- Industrial-grade dust-proof design – sealed sorting chamber and electrical enclosure, suitable for high-dust production environments.
- Integrated dust control system – mature and reliable, ensuring long-term continuous and stable operation.
- Modular chute configuration – supports 1/4/6/8/10/12 channels, flexibly matching different throughput requirements.
II. AI-Powered 4-in-1 Smart Optical Sorting System
- Self-developed deep learning algorithm – continuously trains and optimizes with new samples, enabling evolving defect recognition capabilities.
- High-resolution RGB color imaging – precisely captures subtle surface defects on fava beans.
- High-brightness LED lighting system – ensures clear imaging and uniform illumination, reducing interference from ambient light.
- Expandable camera options – optional NIR camera or InGaAs‑SWIR camera to meet a wider range of inspection needs.
Industry-leading defect detection for fava beans (based on color, size, shape, and texture):
| Defect Category | Description |
|---|---|
| Off-color kernels | Moldy, oxidized, immature, or contaminated fava beans |
| Broken / cracked | Damaged or cracked beans |
| Insect damage | Beans with insect holes or damage |
| Disease spots | Beans infected with fungal or bacterial spots |
| Foreign material | Stalks, stones, glass, plastic, metal, and other impurities |
Supports custom parameter settings for different fava bean varieties, enabling fast product changeovers.
III. High-Performance Pneumatic Ejector System
- Optimized design for durability, high-speed response, and air efficiency.
- Maintains precise ejection and stable performance under high-throughput conditions.
- Significantly reduces false rejection rate, lowering material loss and total operating costs.
IV. 15-Inch Industrial Touchscreen Control System
- Intuitive HMI with multi-language support.
- One‑click switching of product sorting parameters for easy and efficient operation.
- Comprehensive remote support:
- Remote access & real‑time monitoring
- Performance data dashboard
- Online expert diagnostics
- Interactive fault troubleshooting
