Z RGB Optical Sorter Each Channel Is Equipped With 64 High-precision Pneumatic Nozzles, Forming A Cost-effective And Efficient RGB Optical Sorting System.
Each channel is equipped with 64 high-precision pneumatic nozzles, forming a cost-effective and efficient RGB optical sorting system. As a classic bestseller of the PHOENIX glutinous rice color sorter lineup, the Z Series has long been a benchmark in conventional glutinous rice color sorting and is widely trusted by users.
Specifications
| Model | Chute | Air Nozzle | Air Pressure (MPa) | Air Consumption (L/min) | Power (kW) | Voltage | Dimension (L*W*H)(mm) | Weight* (kg) |
|---|---|---|---|---|---|---|---|---|
| Z1 | 1 | 64 | 0.6~0.8 | <1000 | 0.9 | 220V ~ 50/60Hz | 1255*2199*2076 | 680 |
| Z4 | 4 | 256 | 0.6~0.8 | <2000 | 2.9 | 220V ~ 50/60Hz | 2170*2199*2076 | 1150 |
| Z6 | 6 | 384 | 0.6~0.8 | <3000 | 4.4 | 220V ~ 50/60Hz | 2800*2199*2076 | 1480 |
| Z8 | 8 | 512 | 0.6~0.8 | <4000 | 5.9 | 220V ~ 50/60Hz | 3430*2199*2076 | 1840 |
| Z10 | 10 | 640 | 0.6~0.8 | <5000 | 7.3 | 220V ~ 50/60Hz | 4070*2199*2076 | 2180 |
| Z12 | 12 | 768 | 0.6~0.8 | <6000 | 8.8 | 220V ~ 50/60Hz | 4835*2199*2076 | 2550 |
Technical Features
- A cost-effective optical sorting solution tailored for glutinous rice, balancing superior performance and economic benefits.
- Fitted with a high-efficiency vibratory feeder to spread glutinous rice into an even single layer, minimizing grain overlap and improving sorting accuracy.
- Fully enclosed sorting chamber and electrical cabinet with industrial dustproof design, delivering reliable operation in heavily dusty production environments.
- Integrated proven dust removal control system to maintain stable performance during long-hour continuous operation.
- Flexible modular design with chute options of 1, 4, 6, 8, 10 and 12 lanes, meeting production demands from small-batch to large-scale processing.
This integrated system combines high-resolution RGB cameras and high-intensity LED lighting modules. It accurately identifies and locates various defects of glutinous rice by analyzing color, size and shape, including:
- Discolored grains: yellow rice, red rice, dark spots and stains
- Diseased and moldy grains
- Broken and cracked grains
- Immature green grains
- Foreign matters: chaff, straw, stones, glass, plastic, metal and other impurities
The optimized valve structure features outstanding durability, fast response and low air consumption.
It ensures precise and consistent rejection even under high-capacity working conditions.
The low false rejection rate effectively reduces raw material waste and overall operational costs.
- Intuitive human-machine interface with one-click multi-language switching for easy operation.
- Built-in sorting parameter memory enables quick switch between different materials to boost productivity.
- Supports remote access and real-time monitoring to check equipment status anytime, anywhere.
- Equipped with a performance dashboard displaying key operational data clearly.
- Online expert diagnosis for rapid troubleshooting of potential issues.
- Interactive fault guidance to help on-site staff resolve common malfunctions efficiently.
