ISO9001 Extension Silver Rigid Clamp Coupling 16mm To 50mm Aluminum Alloy
Custom Aluminum Alloy Shaft Coupling Rigid Clamping Coupling
Overview
Rigid clamping coupling is a torsionally rigid coupling. Even when it is under load, there is no backlash. Even when the load is caused by deviation, the rigid coupling still transmits torque rigidly.
| Product Name | Rigid Clamping Coupling |
| Type | Separate Screw Locking |
| Material | Aluminum Alloy |
| Color | Silver |
| Feature | Light, Ultra Low Inertia, and High Sensitivity |
| Application | Motion Control |
| Brand Name | OEM |
| MOQ | Small Orders Accepted |
| Tolerance | 0.01-0.05mm |
| Delivery | DHL Fedex TNT UPS Seashipment |
Dimensions of Rigid Clamping Coupling
| D | L | d1, d2 Shaft Diameter | L1 | M | Tightening (N.m) |
| 16 | 16 | 4 5 6 | 4 | M3 | 1 |
| 20 | 20 | 6 8 | 5 | M3 | 1 |
| 25 | 25 | 8 10 12 | 6 | M4 | 1.5 |
| 32 | 32 | 10 12 14 16 | 8 | M4 | 2.5 |
| 40 | 40 | 12 12.7 14 16 18 | 10 | M4 | 3.5 |
| 50 | 50 | 15 16 18 20 22 | 12 | M5 | 5 |
Technical Specification of Rigid Clamping Coupling
| Rated Torque (N.m) |
Max. Torque (N.m) |
Max. Speed (min-1) |
MOI (kg.m2) |
| 0.3 | 0.6 | 12000 | 3.2 x 10-7 |
| 0.5 | 1 | 10000 | 8.7 x 10-7 |
| 1 | 2 | 9500 | 2.7 x 10-6 |
| 2 | 4 | 7500 | 9.3 x 10-6 |
| 3 | 6 | 6100 | 1.5 x 10-5 |
| 4 | 8 | 4500 | 2.8 x 10-5 |
FAQs
Q1: Are you manufacturer or trading company?
A1: We are manufacturer with more than 10,000 square meters plant.
Q2: Will you provide free samples?
A2: Yes, we will provide free sample for customer to test.
Q3: Can you make CNC machining parts according to our drawings?
A3: Yes, we can make the parts according to your drawings.
Q4: Can you make CNC machining parts according to samples?
A4: Yes, we can make the parts according to your samples.
Q5: Which shipping method will you use for delivery?
A5: It depends on customer. Our price is based on FOB, customer needs to afford the shipping. But we are happy to help based on request.
Q6: What’s your payment terms?
A6: We accept T/T, Western Union, Money Transfer, TAAJ, etc.
