0.075mm Power PCB Assembly Service
PCB Electronic Printed Circuit Board Maker Power Supply Board PCB Assembly
About us:
Was founded in year of 2010 .With being OEM manufacturer specializing in PCB/PCBA Sensors etc with 11-year,nowadays,we have built up our strong product research and development center and we are devoting ourselves to electronics smart product. combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers one stop Service
requirements – from front end engineering through to in time deliveries.
PCB Service
ZYX offers pcb production services from1~20Layer For Rigid,1~4Layer for flexible,1~16layer Rigid-Flex pcb.The materials includes standard FR4, High TG FR4,
Aluminum,Polyimide and your Request !
Components sourcing
ZYX offers electronics components souring service ., All IC chips , transistors , crystals .… are new and original . The quality of all components can be assured after 10years experience ,High quality and Low cost
Programming/ Function Testing
ZYX offers programming and function testing services. HEX file and BiN file are available for IC program work by us. For The Function testing ,please prepare detailed testing instruction and documents or more detailed guide
|
Model Number: |
ZYX-21731QDYO |
Place of Origin: |
Shenzhen, China |
|
Copper Thickness: |
0.5-4 0z |
Brand Name: |
BQZYX+ |
|
Product name: |
PCBA and CPB Assembly |
Min. Line Spacing: |
0.075mm |
|
Min. Hole Size: |
0.0078"(0.2mm) |
MOQ: |
1pcs |
|
Min. Line Width: |
0.075mm |
Silkscreen Min size: |
0.006"(0.15mm) |
ZYX is a professional OEM manufacturer for PCB design, PCB production, component souring and SMT assembly,
we sincerely would like to be your reliable OEM supplier from China.
With more than 11 years experience in the PCB industry, our services
Includes:
- PCB&PCBA Contract Manufacturing
- Reverse Engineering Services
- PCB Design and Assembly
- Component Procurement & Material Management
- Product Design
- Fast PCB&PCBA Prototyping
- Cable and Wire Assemblies
- Plastics and Molds
- AOI,X-Ray Testing, other Function Testing Service
|
Images |
|
|
Min Trace Width (a) |
0.075mm (3mil) |
|
Min Space Width (b) |
0.1mm (4 mil) |
|
Min Annular Ring |
0.1mm (4 mil) |
|
SMD Pitch (a) |
0.2 mm(8 mil) |
|
BGA Pitch (b) |
0.2 mm (8 mil) |
|
Solder Mask |
|
|
Min Solder Mask Dam (a) |
0.0635 mm (2.5mil) |
|
Solder mask Clearance (b) |
0.1mm (4 mil) |
|
Min SMT Pad spacing (c) |
0.1mm (4 mil) |
|
Solder Mask Thickness |
0.0007"(0.018mm) |
|
Holes |
|
|
Min Hole size (CNC) |
0.2 mm (8 mil) |
|
Min Punch Hole Size |
0.9 mm (35 mil) |
|
Hole Size Tol (+/-) |
PTH:±0.075mm;NPTH: ±0.05mm |
|
Hole Position Tol |
±0.075mm |
|
Plating |
|
|
HASL |
2.5um |
|
Lead free HASL |
2.5um |
|
Immersion Gold |
Nickel 3-7um Au:1-5u'' |
|
OSP |
0.2-0.5um |
|
Outline |
|
|
Panel Outline Tol (+/-) |
CNC: ±0.125mm, Punching: ±0.15mm |
|
Beveling |
30°45° |
|
Gold Finger angle |
15° 30° 45° 60° |
|
Certificate |
ROHS, ISO9001:2008, SGS, certificate |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation from us?
For PCB board, you need to prepare files of Gerber file,it should including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB, you also need to prepare the BOM list (components list), Pick and Place file(txt format), real sample pictureor 3D PDF version file etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the components
quantity,if simple, within 6 hours can finished,once complex and more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will priority to deal it and do ourbest to give you satisfied delivery time.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
