6m Standard Length Wire Wrapped Continuous Slot Johson Water and Oil Well Screens with Q235 Mild Steel Material
6m Standard Length Wire Wrapped Continuous Slot Johson Water and Oil Well Screens with Q235 Mild Steel Material
Product Description:
Experience the strength and precision of our Wire Wrapped Screens, meticulously crafted for water and oil well applications. These screens are constructed by wrapping wedge wire around a circular or V-shape array of spacing rods, ensuring exceptional durability and filtration accuracy. Our Wire Wrapped Screens are available in standard lengths of 6 meters, with a variety of diameter and wedge wire size options to suit your specific needs.
Features:
- Product Name: Wire Wrapped Screens
- Standard Lengths: 3m and 6m (actual lengths 2.9–2.95m and 5.8–5.95m to fit containers)
- Support Wire: 1x2mm to 4x7mm and more
- Material: Q235 Mild Steel, with options for Duplex Stainless Steel 2205, 904L
- Diameter Range: 1" to 20"
- Applications: Filtration, separation, water treatment, oil and water well drilling, seawater treatment, and more
- Wedge Wire Wrapped Screen Plate
- Wire Wrapped Water Well Screen
- Wire Wrapped Nozzle Screen
- Wire Wrapped Underground Water Well Screen
- Wire Wrapped Gravel Prepacked Screen
Technical Parameters:
| Parameter | Description |
|---|---|
| Standard length | 3m, 6m (actully 2.9-2.95m, 5.8-5.95m To Fit Container) |
| Diameter | 1", 2", 3", 4-1/2", 5", 6-5/8", 8-5/8", 9-5/8", 10-3/4", 12-3/4", 14", 16", ..., 20”, Etc |
| Roundness | Pure Round And Angular |
| Mild Steel Material | Q235, Q195 |
| Surface Treatment | Electrolytic Polishing, Pickling, Galvanizing, No Burrs, Smooth, Brightetc. |
| Duplex stainless steel | 2205,904L |
| Support rods | 2.5-6mm |
| Length range | 0.5-6m (10ft, 20ft) |
| Slot size | 0.05mm-10.0mm |
| End connection | Threaded Ends: API STC, BSP, NPT, BSPP, G"; Plain End: Welded Rings; Flange |
Applications:
Our XinLu wire wrapped screens are the perfect solution for a multitude of filtration and separation needs. With their high strength, precision, and corrosion resistance, these screens are ideal for use in water treatment, oil and gas, chemical, food and beverage industries.
Customization:
Stainless Steel Wire Wrapped Screen, Wire Wrapped Sand Screen, Wire Wrapped Screen Plate, Wire Wrapped Pipe Screen
| Specification | Details |
|---|---|
| Material | Mild Steel (Q235, Q195), Duplex Stainless Steel (2205, 904L) |
| Standard Length | 3m and 6m (actual 2.9-2.95m and 5.8-5.95m) |
| Support Wire | Various sizes up to 4x7mm |
| Support Rods | 2.5-6mm |
| Roundness | Pure Round and Angular |
| Wedge Wire Sizes | 0.75x1.8mm to 4x7mm |
Support and Services:
Our team is dedicated to providing you with the highest level of customer service and technical support. We offer advice and assistance on the installation and operation of our products and are always available to answer any queries you may have.
Packing and Shipping:
Our wire wrapped screens are carefully packed in strong wooden crates or cases, wrapped in protective plastic sheets, and secured with metal straps for safe transit. We ensure that every package is well-protected against weather or debris during shipping.
