RO Sea water seawater desalination plant for boat

Price Negotiable
Price: USD4000-USD6000
MOQ: Negotiable
Delivery Time: Negotiable
Brand: JISHUI
Product Description

 RO Sea water seawater desalination plant for boat

Why we  make you trust  our RO seawater desalination plant?

1. Seawater desalination use automatic control and semi-control.Pretreatment parts can adopt fiber glass or stainless steel material.
2.RO seawater desalination plant has protected when no power, poor power, larger electrical current, leakage, short circuit.
3. Seawater desalination is compact, easy installation.
4. RO seawater desalination plant equipped with manual and auto control based on user needed.
5. Seawater desalination produce as per ISO and SGS standard and main parts accessories have obtained CE certification.
6. All the plants will be commissioning well. Make sure don't have any problem when arrived site.
7.What we provide not only the good products, but also our whole team, the quality, experience, and service.



Applications of seawater desalination plant for boats

·WHO Safe Drinking water. Seawater desalination plant for boats can be operated at room temperature (5-40℃), with excellent water production, low energy consumption and low cost.

·Can be designed according to the particularity of the ship to achieve small in size, light in weight, small in area, easy to install , convenient installation, strong adaptability.

·Can be installed in narrow spaces such as engine room, deck, cabin, aisle, etc

·Simple operation and convenient maintenance.

·Can increase the total amount of fresh water, and is not affected by time, space and climate.

·The water quality is good and the price is gradually reasonable.





Our RO sea water desalination plant|seawater desalination plant for boats have below function:

1.SS316 frame, beautiful appearance, durable in use.

2.Stainless steel Swivel caster, durable in use, easy to more device.

3.To use hose which could reduce vibration and lower noise.

4.5micron fold filter element and 1 micron filter. It will intercept the more than absolutely 5 micron impurities. To avoid them into High pressure pump cause the pump be damaged.

5. Four stainless steel adjusting feet, whether the ground is flat, the equipment can be placed upright, easy to use.

6. Low and full water level switch in the source tank and fresh water tank.

7. Alarm reminding.

8. Online water quality monitor.

9. On/Off/Automatic Mode one key auto flush and start on.



RO sea water desalination plant parameter



Below is 10m3/day seawater desalination plant





10000LPD (10m3/day)RO seawater desalination plant:

 We have more sizes and output water capacity for your choice:

According to customers' water source analysis report and the final water standard required ,we will suggest customer to choose the suitable water treatment system.

Sea recovery watermakers prices village marine watermaker are usable anywhere from yachts to sailboats. It’s important to choose the correct materials of construction to handle seawater (which is highly corrosive).

RO seawater desalination plant Process Flow :



 RO seawater desalination plant  Production process flow introduction.



NOS.

Items

Information

1. Pre-treatment part

1.1

Sand filter

Remove turbidity, SS matter, organic matter, colloid, etc.

2. RO part

2.1

High pressure pump

Provide power for RO.

2.2

PP filter

Prevent large particles, iron, dust, SS matter,

impurity into RO membrane.

2.3

RO membrane

Removes: lead, cooper, barium, chromium, mercury,

sodium, cadmium, fluoride, nitrite, nitrate, and selenium.

3. Electricity control system

3.1

PLC +Touch screen control system

Import from Japan and Taiwan. WeiNveiw, Mitsubishi.

3.2

Electricity components

Import from German. Schneider, Omron.

3.3

Pipe and fitting

Adopt domestic famous brands.
