600KG Lab Deionized Water System , FRP demineralization water treatment plant
Demineralized water cost,demineralized water price,Water demineralizer
Please Attention
HY FACTORY OFFER YOU :
1: FACTORY DIRECT PRICE.
2: NICE QUALITY.
3: ONLINE PAYMENT.
4: SUPPORT REFUND AFTER YOUR INSTALLED THE PLANT IF THERE ARE ANY PROBLME.
5: AFTER SALES SERVICES 24/7
6. Letters patent
7. ENGINNER CAN BE OVERSEA INSTALLNATION
We have 2 factories +300 workers+ Qualified engineer+ Engineer Overseas service
Demineralized water cost,demineralized water price,Water demineralizer process function description
1.Demineralized water cost use automatic control and semi-control .Pretreatment parts can adopt fiber glass or stainless steel material.
2. Water demineralizer has protected when no power, poor power, larger electrical current, leakage, short circuit.
3. Demineralized water price is compact, easy installation.
4. Demineralized water cost equipped with manual and auto control based on user needed.
5. Water demineralizer produce as per ISO and SGS standard and main parts accessories have obtained CE certification.
6. All the plants will be commissioning well. Make sure don't have any problem when arrived site.
7.What we provide not only the good products, but also our whole team, the quality, experience, and service.
|
Model |
HY-20m3 PH |
Remark |
|
Product Capacity |
20m3/hr |
|
|
Power supply |
3PH x 380V, 60Hz |
|
|
Feed water pump |
Q=25m3/h |
CNP/CHINA |
|
Sand filter |
Φ1500XH2400mm
|
FRP |
|
Activated carbon filter |
Φ1500XH2400mm
|
FRP/Carbon steel/ stainless steel For client choose |
|
Cation exchange filter
|
Φ1500XH2400mm
|
FRP/Carbon steel/ stainless steel For client choose |
|
Anion exchange filter
|
|
FRP/Carbon steel/ stainless steel For client choose |
|
Resin trap
|
Φ230XH410mm |
SUS304 |
|
Booster pump
|
4040×5pc |
SUS304 |
|
Mixed bed
|
Φ1000XH3300mm |
HY/CHINA |
We are the right supplier. You know why?
Deionized Water System , plant Process Flow:Source tank →Feed water pump → multi-media filter(sands filter) → active carbon filter → water softener(or inhibitor dosing)→PP filter→ high-pressure pump →RO system→PH adjust system →RO tank →Deionized feed pump →Ion exchange column → Deionized water tank → transfer pump → outlet water
Deionized Water System process introduction.
|
NOS. |
Items |
Information |
|
1.Deionized water syste Pre-treatment part |
||
|
1.1 |
Sand filter |
Remove turbidity, SS matter, organic matter, colloid, etc. |
|
1.2 |
Active carbon filter |
Remove color, free chloride, organic matter, harmful matter, etc. |
|
1.3 |
Water softener |
Soft water and reduce it's hardness. |
|
2. Deionized water syste RO part |
||
|
2.1 |
High pressure pump |
Provide power for RO. |
|
2.2 |
PP filter |
Prevent large particles, iron, dust, SS matter, impurity into RO membrane. |
|
2.3 |
RO membrane |
Remves: lead, cooper, barium, chromium, mercury, sodium, cadmium, fluoride, nitrite, nitrate, and selenium. |
|
3. Deionized Water System system part |
||
|
3.1 |
Ion exchange feed water pump |
Provide power for ion exchange system. |
|
3.2 |
Anion and cation exchange filter |
Further removes ions in water. |
|
3.3 |
Security fitler |
Prevent the resin leakage |
|
4. Electricity control system |
||
|
4.1 |
PLC+Touch screen control system |
Japan Mitsubishi. siemens |
|
4.2 |
Electrivity components |
Import from German. Schneider, Omron. |
|
4.3 |
Pipe and fitting |
Adopt domestic famous brands. |
We can customized water demineralized water plant capacity from 250L/hr~50m3/hr.
