Outdoor Underground Cable GYTA 144 Core Fiber Optical Cable Loose Tube Stranded Armoured
Features
- Steel wire as the central strength member
- Hydrolysis resistant loose tube
- Tube filling compound ensures critical protection of fiber
- Specially designed stranded structure eliminating contraction of tubes
- Rugged, durable PE jacket protects against UV radiation, fungus etc.
Application
- Duct
- Non Self-supporting Aerial Installation
Technical Parameter
| Fiber Count | 144 | |
| Outer Dia.(mm) | 13.8 | |
| Tensile Resistance(N) | Long Term | 600 |
| Short Term | 1500 | |
| Crush Resistance(N/100m) | Long Term | 300 |
| Short Term | 1000 | |
| Mini Bending Radius(mm) |
Dynamic | 20D |
| Static | 10D | |
| Attenuation(dB/Km) | 1310nm | ≤0.36 |
| 1550nm | ≤0.22 | |
| Operating temperature(℃) | -40℃+60℃ | |
| N.W.(kg/km) | 190 | |
Company Profile
Sichuan Yuantong Communication Co., Ltd is one of the leading manufacturer in the cables
and telecom accessories. We have more than 20 years experience in this line.
Our productions comply with ISO9001.Professional team,powerful factory and strict quality control give
best service to our clients and the quality guarantee in every order.
Our products have been widely installed in Telecom companies and many distributors around the world.
We have established a close relationship with many companies around the world and we sincerely look
forward to woking with all clients from all over the world.
FAQ
1.Are you the real manufacturer?
We are the real manufacturer with 20 year's history.
2.What's the MOQ?
The MOQ of Fiber Optic cable is 1km.
3.What's delivery time?
The general delivery time is 5-7 working days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Store the drum indoor before using.
5. Can you supply customized products and logo?
We supply OEM service.
6.What's your payment terms?
T/T, L/C,it can be negotiated.
