1800pcs/Hr Natural dry Rotary 3by4 Type Egg Tray Making Machine

Description For Egg Tray Making Machine

Small egg tray machine is the best solution for small-scale or the first investors. It has some advantageous features: low cost, easy operation, small foot space, low risk, etc. More than that, it doesn’t need professional workers. Many of our customers run their egg tray plant with family members only. And the majority of customers related to poultry farmers or egg business use this machine to greatly add the eggs’ value.

Egg Tray Making Machine Process:

1. Pulping system
Pulper, 1.0M3,15kw;
vibration screen, 0.9M2,3kw;
mixer; pulp pump;water pump,control cabinet for pulping system,etc
2. Forming system
Consist of 1pc of forming platen and 1 pc of transfering platen.
Platen size:1100x470mm,4sets of 30-cell egg tray molds can be mounted on forming platen.
Forming efficiency:5-6cycles/min;
Equiped with vacuum auto draining system;auto cleaning system for the forming mold and auto control cabinet.
3. Drying system
Outline dimension:20080x2650x3600mm;
Single layer conveying chain;heated by section;multi burners;
Six layers drying line, energy saving and saving place
The temperature of each section can be adjusted independently;burners with French or Italian brand;
The energy for option: LPG,GAS,diesel oil,Equiped with auto control cabinet.

Process:

Finished product

The machine can make different product just change the mold.eg egg tray,egg carton,fruit tray,shoe tree,coffee carrier and so on.

Drying System

The drying system is the third section of the egg tray production line. Generally, the wet trays moisture content is 70%. So drying system is required for drying the wet trays.for this small capacity machine ,Natural drying method is ok dried directly by weather and natural wind

Main features

High precision motor drive,high efficiency and energy-saving drying line.
1, Use precision reducer motor forming and transferring to ensure smooth and fast operation.
2, Use absolute encoder to achieve accurate correction.
3,The use of bronze casting static and dynamic ring structure is more suitable for product dewatering process.
4, The use of mechanical structure to ensure that the mold close on both sides evenly.
5, Large capacity; Water content is low;Save the cost of drying.

RAQ:

Q: What's the guarantee for the egg tray machine and equipment?
A: Usually the forming machine guarantee is one year, and motors guarantee is half of an year.
Q:How to choose a suitable egg tray making machine and production lines?
A:Just need tell us your requirement.We will make a good production plan according to your requirements.
Q:Do you provide sample service?
A:We can send you paper samples, which is produced by our machine.
You also can send us the paper sample that you want to produce by DHL, etc.We will design according to your paper samples.
Q:What is the raw material of egg tray making machine?
A:Waste paper,Cardboard,Magazine,Newspaper,ect
Q:Can you offer technician aboard for training workers?
A:Yes, we have team for installation guidance aboard, technicians will be sent for installation guidance and training workers .
Q:Where is your company located?
A: it is located in Shijiazhuang city,Hebei province, China.

Flow Chart

Factory show and customers
