Custom Made Bending Taper Quartz Glass Rod For Medical Equipment
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
5-8 working days
Brand:
ZCQ
Product Description
Custom Made Bending Taper Quartz Glass Rod Used for Medical Equipment
This tapered quartz glass rod is made of high purity silica glass, with requried bending angle.
| Properties | Value | |
| Mechanical Properties | Density | 2.203g/cm3 |
| Compressive Strength | 1100Mpa | |
| Bending Strength | 67Mpa | |
| Tensile Strength | 48.3Mpa | |
| Poisson's Ratio | 0.14～0.17 | |
| Young’s Modulus | 72000Mpa | |
| Rigidity Modulus | 31000Mpa | |
| Mohs Hardness | 5.5～6.5 | |
| Thermal Properties | Deformation Point | 1280℃ |
| Softening Point | 1680℃ | |
| Annealing Point | 1210℃ | |
| Specific Heat (20～350℃) | 670J/kg.℃ | |
| Thermal Conductivity (20℃) | 1.4W/m.℃ | |
| Coefficient of thermal expansion | 5.5×10-7cm/cm.℃ | |
| Hot Work Temperature | 1700～2000℃ | |
| Short-term Use Temperature | 1300℃ | |
| Long-term Use Temperature | 1100℃ | |
| Electrical Properties | Resistivity | 7×107Ω.cm |
| Dielectric Strength | 250～400Kv/cm | |
| ε/ Dielectric Constant | 3.7～3.9 | |
| Dielectric absorption coefficient | <4×104 | |
| Dielectric loss coefficient | <1×104 | |
