Aluminum Expanded Metal Screen Mesh Curtain Wall Galvanized Building Design Material
We are specializing in expanded metal lath and accessories, including rib laths, diamond meshes, corner beads, plaster stop beads, weep screeds, high rib formworks and so on.
Regular Expanded Metal Lath is a multi-purpose plaster base and reinforcement, which has been used successfully for over 100 years. Expanded Metal Lath is an outstanding plaster base used for walls, ceilings and ceramic tile. The flat surface is easily cut and can be formed to fit curved surface.
Usage:
Expanded Steel/Aluminium Sheet can be used as steel reinforcement materials in petroleum, chemical industry and building decorations, fencing for road, railway, civil building, water conservancy's construction; protecting of all kinds of machines, electrical equipment, window and aquatic product's breeding etc.
Material:
Expanded metal mesh can be made from a wide range ofmaterials, chiefly expanded steel mesh,
aluminum expanded metal mesh, expanded stainless steel, expanded nickel and other metal.
Features:
Thickness available from 0.5mm to 8mm.
Weaving method:
stamping
| Item No. |
Thickness of Aluminium Sheets (mm) |
Nominal Size of Mesh Opening (mm) | Standard Dimension of AL Expanded Mesh | Calculated Weight (kgs/m2) |
|||
| SWD (mm) |
LWD (mm) |
Strand (Strand Width, mm) |
LWM (Width, mm) |
SWM (Length, mm) |
|||
| 1 | 0.5 | 3 | 6 | RC | 100 | RC | 0.6 |
| 2 | 0.5 | 3.2 | 8 | RC | 200 | 2000 | 0.6 |
| 3 | 0.5 | 5 | 10 | RC | RC | RC | 0.6 |
| 4 | 0.5 | 6 | 12.5 | RC | 1800 | 3000 | 0.37 |
| 5 | 0.5 | 7 | 14 | RC | 1800 | 3000 | 0.37 |
| 6 | 0.5 | 8 | 16 | RC | 2000 | 3340 | 0.37 |
| 7 | 0.5 | 9 | 20 | RC | 2000 | 3340 | 0.37 |
| 8 | 0.5 | 10 | 25 | 1.12 | 2000 | 4000 | 0.3 |
| 9 | 0.5 | 12 | 30 | 1.35 | 1800 | 3600 | 0.3 |
| 10 | 0.8 | 10 | 25 | 1.12 | RC | RC | 0.3 |
| 11 | 0.8 | 12 | 30 | 1.35 | RC | RC | 0.48 |
| 12 | 0.8 | 15 | 40 | 1.68 | RC | RC | 0.48 |
| 13 | 1 | 10 | 25 | 1.12 | RC | RC | 0.48 |
| 14 | 1 | 12 | 30 | 1.35 | RC | RC | 0.6 |
| 15 | 1 | 15 | 40 | 1.68 | RC | RC | 0.6 |
| 16 | 1.2 | 10 | 25 | 1.13 | RC | RC | 0.6 |
| 17 | 1.2 | 12 | 30 | 1.35 | RC | RC | 0.73 |
| 18 | 1.2 | 15 | 40 | 1.68 | RC | RC | 0.73 |
| 19 | 1.2 | 18 | 50 | 2.03 | RC | RC | 0.73 |
| 20 | 1.5 | 15 | 40 | 1.69 | RC | RC | 0.91 |
| 21 | 1.5 | 18 | 50 | 2.03 | RC | RC | 0.91 |
| 22 | 1.5 | 22 | 60 | 2.47 | RC | RC | 0.91 |
| 23 | 1.5 | 29 | 80 | 3.25 | RC | RC | 1.21 |
| 24 | 2 | 18 | 50 | 2.03 | 1800 | 3600 | 1.21 |
| 25 | 2 | 22 | 60 | 2.47 | 2000 | 4000 | 1.21 |
| 26 | 2 | 29 | 80 | 3.26 | 2500 | 5000 | 1.52 |
| 27 | 2 | 36 | 100 | 4.05 | RC | RC | 1.52 |
| 28 | 2 | 44 | 120 | 4.95 | RC | RC | 1.82 |
| 29 | 3 | 36 | 100 | 4.05 | RC | RC | 1.82 |
| 30 | 3 | 44 | 120 | 4.95 | RC | RC | 1.82 |
| 31 | 3 | 55 | 150 | 4.99 | 2000 | 5000 | 1.47 |
| 2500 | 6400 | ||||||
| 32 | 3 | 65 | 180 | 4.60 | 2000 | 6400 | 1.14 |
| 2500 | 8000 | ||||||
| 33 | 4 | 22 | 60 | 4.50 | 1500 | 2000-3000 | 4.42 |
| 34 | 4 | 30 | 80 | 5 | RC | 2000-4000 | 3.60 |
| 35 | 4 | 38 | 100 | 6 | 2000 | 2000-4500 | 3.41 |
| 36 | 5 | 24 | 60 | 6 | RC | 2000-3000 | 6.76 |
| 37 | 5 | 35 | 80 | 6 | RC | 2000-4000 | 5.07 |
| 38 | 5 | 38 | 100 | 7 | RC | 2000-4500 | 5.05 |
| 39 | 5 | 56 | 150 | 6 | RC | 2000-6000 | 2.90 |
| 40 | 5 | 76 | 200 | 6 | RC | 2000-6000 | 2.13 |
| 41 | 6 | 32 | 80 | 7 | RC | 2000-4000 | 7.10 |
| 42 | 6 | 38 | 100 | 7 | RC | 2000-4500 | 5.98 |
| 43 | 6 | 56 | 150 | 7 | RC | 2000-6000 | 4.05 |
Customize Design Anti-Corrosive Expanded Metal Mesh
Features:
Weight is light enough for outer wall hanging
Anti-corrosive
Rainstorm or isolation won`t hurt
Visibility and colorful
Used as decorative mesh for building outer wall ,radiator cover mesh
Easily fabricated, finished, installed and formed
Application
expanded metal used with concrete in buildings and construction, maintenance of equipment,
making of arts and crafts, covering screen for first class sound case. Also fencing for super highway,
studio,highway.
Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.It have been 15 years that we manufacture and exported wire mesh product,our main product is stainless steel woven wire mesh,we keep the good manufacture technique of wire mesh product,to client orders,we will finish it within our shortest production time while keep mesh quality.
