High Strength Welded Wire Fence Panels 4.2mm Thickness
high strength 4.2mm thickness welded wire mesh panel for fence
Product Introduction
The finished welded wire mesh panels offer flat and uniform surface, firm structure, good integrity. The welded wire mesh panels are the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields. The welded wire mesh panels can be galvanized, PVC coated, or stainless steel welded wire mesh.
Product Specification
|
Material |
Low carbon steel wire Q195, Q235, stainless steel |
|
Surface |
Black wire, re-drawing wire, electroc galvanized, hot dipped galvanized wire, PVC coated |
|
Wire Diameter |
1mm-10mm |
|
Hole (mesh) |
2.5-25cm |
|
Length |
≤8m |
|
Width |
0.5-3m |
|
Package |
iron pallet or nude packing |
|
Wire diameter(mm) |
Vertical spacing(mm) |
Horizontal spacing(mm) |
Length(m) |
|
10 |
100-500 |
30-300 |
1-8 |
|
9 |
100-500 |
30-300 |
1-8 |
|
8 |
100-500 |
30-300 |
1-8 |
|
7 |
50-200 |
20-300 |
1-8 |
|
6 |
50-200 |
20-200 |
1-8 |
|
5 |
50-200 |
10-200 |
1-8 |
|
4 |
30-200 |
10-200 |
1-8 |
|
2-4 |
25-100 |
10-100 |
1-6 |
|
1 |
33 |
15-80 |
2.2 |
|
Specification |
||||
|
Opening |
Wire Diameter |
Width 0.4-2m Length 5-50m |
electric galvanized before welded, electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire
|
|
|
Inch |
Metric Unit |
|||
|
1/4"x1/4" |
6.4mmx6.4mm |
BWG24-22 |
||
|
3/8"x3/8" |
10.6mmx10.6mm |
BWG22-19 |
||
|
1/2"x1/2" |
12.7mmx12.7mm |
BWG23-16 |
||
|
5/8"x5/8" |
16mmx16mm |
BWG21-18 |
||
|
3/4"x3/4" |
19.1mmx19.1mm |
BWG21-16 |
||
|
1"x1/2" |
25.4mmx25.4mm |
BWG21-16 |
||
|
1-1/2"x1 1/2" |
38mmx38mm |
BWG19-14 |
||
|
1"x2" |
25.4mmx12.7mm |
BWG16-14 |
||
|
2"x2" |
50.8mmx50.8mm |
BWG15-12 |
||
|
2"x4" |
101.6mmx101.6mm |
BWG15-12 |
||
|
4"x4" |
101.6mmx152.4mm |
BWG15-12 |
||
|
4"x6" |
101.6mmx152.4mm |
BWG15-12 |
||
|
6"x6" |
152.4mmx152.4mm |
BWG15-12 |
||
|
6"x8" |
15.4mmx203.2mm |
BWG14-12 |
||
|
Note:Special specification can be made according to customers requires. |
||||
Application:
industry,
agriculture,
breeding,
construction,
transportation,
mining,
other aspects.
Packing :
The package can be customized.
Common package: iron pallet + waterproof paper+ safety belts.
