AS/NZS4671 Standard Galvanized Welded Mesh Panels For Underground Supporting
Price:
USD14.50-58.50/PC
MOQ:
100PCS
Delivery Time:
5-7days
Brand:
X MESH
Product Description
AS/NZS4671 Standard Galvanized Welded Mesh Wire Panels Sheets for Underground Supporting
Galvanized Welded Mesh Introduction:
Mine Welded Wire Mesh support is a kind of support method in deep foundation pit support project. It is the shortened form for joint support of shotcrete, bolt and steel mesh, as an advanced support and reinforcement technology, in rock soil high slope and large span underground works, especially under adverse geological conditions, extensive and successful applicated at home and abroad.
Product Name |
Galvanized Welded Mesh |
Material |
Galvanized Steel Wire |
Wire Diameter |
6mm |
Mesh Opening |
150mm x 150mm |
Width |
2.4m |
Length |
6.0m |
Feature |
Smooth surface & Anti-erosion |
Application |
for Understandground Supporting |
Packing |
Pallet or Wooden Case Packing |
Standard |
AS/NZS4671 Standard |
Galvanized Welded Mesh Specification:
Mesh Panel Common Specification |
|||
Mesh |
Wire Diameter |
||
Expressed in Inches |
Millimeters |
Diameter |
Millimeters |
1" × 1" |
25 mm × 25 mm |
11 G - 14 G |
2 mm - 3 mm |
2" × 1" |
50 mm × 25 mm |
8 G - 14 G |
2 mm - 4 mm |
2" × 2" |
50 mm × 50 mm |
8 G - 14 G |
2 mm - 4 mm |
3" × 2" |
75 mm × 50 mm |
6 G - 14 G |
2 mm - 5 mm |
3" × 3" |
75 mm × 75 mm |
6 G - 14 G |
2 mm - 5 mm |
4" × 2" |
100 mm × 50 mm |
4 G - 14 G |
2 mm - 6 mm |
4" × 4" |
100 mm × 100 mm |
4 G - 14 G |
2 mm - 6 mm |
5" × 5" |
125 mm × 125 mm |
4 G - 14 G |
2 mm - 6 mm |
6" × 6" |
150 mm × 150 mm |
4 G - 14 G |
2 mm - 6 mm |
Max Width :2400mm , Max Length : 6000 mm |
|||
Note: Special specifications can be customized. |
|||
Mechanical Properties
Component |
Strength |
Standard |
Wire |
Tensile 500-750MPa |
AS/NZS4671:2001 |
Weld Shear Strength |
ISO15630-2 |
|
Galvanising |
AS/NZS4534-2006 |
Galvanized Welded Mesh Feature:
High tensile strength
Smooth surface
Anti-erosion
anti-aging
anti-sunburn
Easy installation.
Galvanized Welded Mesh Application:
Slab on Grade reinforcement |
Floor and Walls Systems |
Topping Slabs |
ArchiteFloor and Walls Systemsctural precast wall panels |
Tilt-up construction wall systems |
Shear walls |
Retaining walls |
Mechanically Stabilized Earth (M.S.E.) reinforcement |
