Anti Skid Galvanized Welded Steel Grating Crocodile Mouth Crocodile Lips Grip Strut
Price:
USD8.5-25.5/pc
MOQ:
200pcs
Delivery Time:
5-7days
Brand:
X MESH
Product Description
Anti - Skid Galvanized Welded Steel Grating Crocodile Mouth Crocodile Lips Grip Strut
Welded Steel Grating Introduction:
Grtp Strut Grating Plates are one-piece modules manufactured with integral side toe boards projecting above the walking surface of the flooring.
Ideal for elevated applications such as suspended walkways or conveyor catwalks, these channels provide safe, economical,
slip resistant options for long span walkways. Continuous spans can be accommodated by welding adjacent planks or
specifying splice plates as illustrated below.
Name |
Welded Steel Grating |
Diamond Pattern |
3 Diamonds |
Width |
13-3/4" |
Channel Depth |
4" |
Thickness |
11 Ga., 10 Ga., 9Ga. |
Standard |
ASTM A213 |
Application |
For Commercial |
Feature |
easy install & long using life |
Material |
Mild Steel |
Packing |
Pallet or Wooden Case packing |
Welded Steel Grating Standard:
Implementation standards: GB: GB13296-97, GB/T14976-2002, GB/T14975-2002
American Standard: ASTM A312/A312M, ASTM A213/A213M, ASTM A269/A269M
German standard: DIN 2462
Japanese standard: JIS G3463
Other standards: can be produced according to customer's standard
Welded Steel Grating Specification:
2 Diamond / 9-1/4" Width |
||||
Diamond Pattern |
Width |
Channel Depth |
galvanized |
Aluminum |
2 Diamonds |
9-1/4" |
2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
9-1/4" |
2-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
9-1/4" |
3" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
9-1/4" |
4" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
3 Diamond / 13-3/4" Width |
||||
Diamond Pattern |
Width |
Channel Depth |
galvanized |
Aluminum |
3 Diamonds |
13-3/4" |
2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
13-3/4" |
2-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
13-3/4" |
3" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
13-3/4" |
4" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
5 Diamond / 23-1/4" Width |
||||
Diamond Pattern |
Width |
Channel Depth |
galvanized |
Aluminum |
5 Diamonds |
23-1/4" |
2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
23-1/4" |
2-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
23-1/4" |
3" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
23-1/4" |
4" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
6 Diamond / 27-3/4" Width |
||||
Diamond Pattern |
Width |
Channel Depth |
galvanized |
Aluminum |
6 Diamonds |
27-3/4" |
2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
27-3/4" |
2-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
27-3/4" |
3" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
27-3/4" |
4" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
8 Diamond / 36" Width |
||||
Diamond Pattern |
Width |
Channel Depth |
galvanized |
Aluminum |
8 Diamonds |
36" |
1-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
36" |
2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
36" |
2-1/2" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
36" |
3" |
11 Ga., 10 Ga., 9Ga. |
12 Ga. (.080"), 10 Ga. (.100") |
|
Welded Steel Grating Applications:
It's applies to secure channel, platform, stair treads in sewage treatment, waterworks,power plant,prospecting instrument
and other particular environment.
Welded Steel Grating Feature:
1, low cost, zinc plate is cheaper compare to after hot dipped galvanized
2, easy install, but need think about carrying capacity
3, anti-skid effect is best, there are 14 teeth around one hole, getting hold of the shoes sole when you stand in walkway.
4, low maintain cost.
