0.91 inch 128x32 I2C OLED Display White/Blue Color
General Specifications
| Display Size: | 0.91 inch |
| Display Mode | OLED |
| Dot Matrix | 128*32 |
| Dot Size | 0.159*0.159 mm |
| Dot Pitch | 0.175*0.175 mm |
| Aperture Rate | 82.5% |
| Active Area | 22.384*5.584 mm |
| Drive IC | |
| Resolution: | 128x32 |
| Display color: | Monochrome (White/Blue) |
| Drive method: | 1/32 duty |
| Connector: | FPC |
| Top temp: | -20℃ TO +70℃ |
| Tst temp: | -30℃ TO +80℃ |
| Interface: | 8-bit,4-wire SPI,I2C |
0.91 inch 128x32 I2C OLED Display White/Blue Color
This product is our standard product, with a wide range of products, used in digital products such as game consoles, calculators, small instruments, small equipment control panels and so on. Products can be customized according to customer requirements; if you have any questions about the products, please contact us as soon as possible, we will serve you wholeheartedly, thank you!
FAQ
Q: Do you accept customization displays and touch screens?
A: Sure, you can customization the FPC,Backlight and the touch screen.
Q: What type of interface is your display screen?
A: Small sized of displays generally support SPI,MCU,RGB,MIPI.Medium sized displays generally support LVDS,MIPI,EDP.Different specifications use different interfaces.
Q: Do you used capacitive touch screen or resistive touch screen.
A: We have capacitive touch screen and resistive touch screen .
