1.5KW Bench Hydraulic Press 1T Bench Shop Press 1KN C Type Hydraulic Table Press

Price Negotiable

Price: Negotiable

MOQ: 1pcs

Delivery Time: In 60days

Brand: MEILI

Product Description

Cheap Bench Hydraulic Presses Factory in China

Features:

1. The steel body is entirely welded with steel plates, and treated to relive stress by tempering

2. Cartridge valve integral unit equipment for hydraulic control system, reliable, durable and less hydraulic shock, with shorter connection pipeline and fewer releases points.

3. Independent electrical control, reliable, audio-visual and convenient for maintenance.

4. Centralized button control system, with adjustment, hand and semi-auto operation modes.

5. Fixed stroke forming process of fixed pressure forming process selected through control panel, with pressure hold and time delay functions.

6. The operating force, no-load traveling and, low-speed movement and travel range can be adjusted subject to technological requirements.

Description		Unit	1T	1.6T	2.5T	4T	5T
Nominal Force		KN	1	1.6	2.5	4	5
Table size	L-R	mm	300	300	350	350	350
Table size	F-B	mm	250	250	300	300	350
Max opening height		mm	300	300	350	350	350
Max stroke of slider		mm	120	120	160	160	200
Throat Depth		mm	120	120	160	160	180
Down speed of slider		mm/s	60	50	42	42	42
Return speed of slider		mm/s	80	80	80	80	80
Operation Height		mm	200	200	200	200	200
Powder of motor		KW	1.5	1.5	2.2	2.2	3
