10ton Electric Servo Press 750mm 11KW CNC Automotive Industry
10ton Electric Servo Press 750mm 11KW CNC Automotive Industry
10ton Electric servo press for sale
Major features:
1). Energy saving and emission reduction: Hydraulic and electronic control adopt intelligent servo-saving system, saving 50-70%
2). Safety & Precision: Each machine is equipped with an infrared safety grating, which effectively protects the safety of the operator. The servo intelligent patented control system ensures that the machine’s repeat position accuracy is up to ± 0.03mm and the pressure precision is ± 1 bar.
3). Low failure rate: Servo intelligent patent control system, do not useless work, the oil temperature is not easy to increase, and there is no negative pressure in the oil system, a greater reduction of failure, prolong the service life of hydraulic components, electrical appliances with automatic fault alarm function and one-button reset function.
| Description | Unit | 0.5T | 1T | 2T | 3T | 4T | 5T | 8T | 10T | 20T | |
| Nominal Force | T | 0.5T | 1T | 2T | 3T | 4T | 5T | 8T | 10T | 20T | |
| Table size | L-R | mm | 300 | 300 | 400 | 400 | 400 | 500 | 500 | 500 | 600 |
| F-B | mm | 250 | 250 | 320 | 320 | 320 | 440 | 440 | 440 | 500 | |
| Max daylight | mm | 300 | 300 | 300 | 350 | 400 | 450 | 500 | 500 | 500 | |
| Stroke of slider | mm | 120 | 120 | 150 | 200 | 250 | 250 | 300 | 350 | 350 | |
| Down speed | mm/s | 0-80 | |||||||||
| Working speed | mm/s | 0-15 | |||||||||
| Return speed | mm/s | 0-80 | |||||||||
| Throat Depth | mm | 120 | 120 | 160 | 160 | 180 | 250 | 250 | 250 | 280 | |
| Operation Height | mm | 750 | 750 | 750 | 750 | 750 | 750 | 750 | 750 | 750 | |
| Powder of motor | KW | 1 | 2 | 2 | 3 | 4 | 5 | 7.8 | 11 | 20 | |
