Metal 120KW Medium Frequency Induction Heating Equipment
Metal 120KW Medium Frequency Induction Heating Equipment
Descriptions of induction heating machine:
Our induction heating machines adopt IGBT series and parallel induction heating technology as the core. Heat the workpiece to a certain temperature, and then cool it rapidly to change its machine structure to achieve some special mechanic properties.
Technical parameters of heating equipment:
|
Item Model |
ZP-120 |
| Rated Voltage(V) |
380V/50Hz |
| Input Power(kVA) |
5~120 |
| Input Oscillation Frequency(kHz) |
3~19 |
| Load Duration |
100% |
| Cooling Water Pressure(Mpa) |
0.25~0.4 |
| Output Water Flow(L/Min) |
35~50 |
Main features of medium frequency induction heating machine:
Big power, low frequency and good diathermancy.
High frequency, low power consumption, easy installation and simple operation.
It can continuously work for 24 hours for the comprehensive full load design.
It adopts the IGBT inverter circuit in parallel connection, which ha high load adaptability.
It has functions as over-voltage, over-current, over-heat, phase loss and water shortage alarm indications as automatic control and protection.
Compared with other heating models, it can significantly promote the economic benefits, improve the quality of heated work pieces, save the energy and material, alleviate labor intensity and improve the production environment.
